Trane GECK006 - Page 17

WSHP-SVX022A-EN
17
Figure 12. GEC 0.5 to 1.5 tons (60 Hz) - cabinet (LH) low height unit
4"
3/4"
3/4"
9 5/8"
47 1/4"
7/8"
4"
3/4"
PIPE & ELECTRIC
FIELD HOOK-UP
5"
15 3/4"
(4) .250 WALL SLEEVE
MOUNTING HOLES
48"
FIELD ADJUSTABLE
BI-DIRECTIONAL GRILLES
12"
34 3/4"
1 3/4"
1 1/4"
6" LONG
PLASTIC HOSE
PROVIDED FOR
CONDENSATE
CONNECTION.
1 1/2"
7 3/4"
2 3/4"
3 3/8"
CONTROL
ACCESS
PANEL
4 3/8"
19 3/8"
11 1/4"
10 3/8"
4 7/8"
21 1/4"
19 7/8"
22 1/2"
.625 ODS
WATER OUT
.625 ODS
WATER IN
7/8"
SIDE VIEW
BACK VIEW
FRONT VIEW
TOP VIEW
PIPE & ELEC.
FIELD HOOK-UP
BACK OF UNIT
4 7/8"
RECEPTACLE BOX
9 1/4"
PLASTIC DRAIN CONN.
.625 I.D.
20 1/2"
Unit Dimensions
