Table 51. Fixed speed staging sequence and compressor data
25T (Std), 30T (Std), 30T (High)
Stage Comp 1A Comp 1B Comp 1C
1 X
2 X
3 X X
4 X X
5 X X X
25T (High)
Stage Comp 1A Comp 1B
1
X (Unloaded)
2
X (Loaded)
3 X
4 X
X (Unloaded)
5 X
X (Loaded)
40T - 130T (All Std. and High Efficiency Systems)
Stage Comp 1A Comp 1B Comp 2A Comp 2B
1 X
2 X X
3 X X X
4 X X X X
Table 52. eFlex™™ staging sequence and compressor data
20 Ton eFlex™ Variable Speed Compressor
Stage Comp 1A VZH088 Comp 1B
VZH
Min Spd Max Spd
1 X 1500 5820
2 X X 1500 5400
25 Ton eFlex™ Variable Speed Compressor
Stage Comp 1A VZH088 Comp 1B
VZH
Min Spd Max Spd
1 X 1620 6000
2 X X 1500 6000
30 Ton eFlex™ Variable Speed Compressor
Stage Comp 1A VZH117 Comp 1B
VZH
Min Spd Max Spd
1 X 25 100
2 X X 25 83
40 Ton eFlex™ Variable Speed Compressor
Stage Comp 1A VZH117 Comp 2A Comp 2B
VZH
Min Spd Max Spd
