Table 72. Condenser fan VFD parameters (continued)
Menu ID
Descriptions Parameter Setting
Commu-
nica-
tions
and
Opera-
tions
8-30 Protocol
[2] Modbus RTU
8-31 Address
Set address per unit component location diagram
[5] for 1A (REFDES 2M6) [
6] for 2A (REFDES 2M9)
8-32 Baud Rate
[7] 115200 Baud
8-33
Parity / Stop Bits [0] Even Parity,1 Stop Bits
8-35
Minimum Response
Delay (s)
[0.005] 5ms Min Response Delay Time
8-36
Maximum Response
Delay (s)
[0.1] 100ms Max Response Delay Time
8-01 Control Site
[2] Controlword only
8-03
Control Timeout Time
(s)
[15] 15s
8-04
Control Timeout
Function
[2] Stop
Special
Func-
tions
14-01
Switching Frequency
(kHz)
[5] 5.0 kHz
14-11
Mains Voltage Fault
level (V)
Set based on motor nameplate voltage
[391] for 460V motor
[489] for 575V motor
14-12
Function at Main
Imbalance
[3] Derate
14-20 Reset Mode
[3] Automatic reset x 3
14-50 RFI Filter
[0] Off
14-61
Function at Inverter
Overload
[1] Derate
eFlex™ Compressor VFD Programming
Parameters
WWAARRNNIINNGG
HHaazzaarrddoouuss VVoollttaaggee ww//CCaappaacciittoorrss!!
FFaaiilluurree ttoo ddiissccoonnnneecctt ppoowweerr aanndd ddiisscchhaarrggee
ccaappaacciittoorrss bbeeffoorree sseerrvviicciinngg ccoouulldd rreessuulltt iinn ddeeaatthh oorr
sseerriioouuss iinnjjuurryy..
DDiissccoonnnneecctt aallll eelleeccttrriicc ppoowweerr,, iinncclluuddiinngg rreemmoottee
ddiissccoonnnneeccttss aanndd ddiisscchhaarrggee aallll mmoottoorr ssttaarrtt//rruunn
ccaappaacciittoorrss bbeeffoorree sseerrvviicciinngg.. FFoollllooww pprrooppeerr
lloocckkoouutt//ttaaggoouutt pprroocceedduurreess ttoo eennssuurree tthhee ppoowweerr
ccaannnnoott bbee iinnaaddvveerrtteennttllyy eenneerrggiizzeedd.. FFoorr vvaarriiaabbllee
ffrreeqquueennccyy ddrriivveess oorr ootthheerr eenneerrggyy ssttoorriinngg
ccoommppoonneennttss pprroovviiddeedd bbyy TTrraannee oorr ootthheerrss,, rreeffeerr ttoo
tthhee aapppprroopprriiaattee mmaannuuffaaccttuurreerr’’ss lliitteerraattuurree ffoorr
aalllloowwaabbllee wwaaiittiinngg ppeerriiooddss ffoorr ddiisscchhaarrggee ooff
ccaappaacciittoorrss.. VVeerriiffyy wwiitthh aa CCAATT IIIIII oorr IIVV vvoollttmmeetteerr
rraatteedd ppeerr NNFFPPAA 7700EE tthhaatt aallll ccaappaacciittoorrss hhaavvee
ddiisscchhaarrggeedd..
A factory-shipped TRV200 should not be modified in
the field. It is specifically matched to the compressor.
Should replacing a VFD become necessary, refer to . All
other parameters will be appropriately set in field
replacement VFDs. Do not use any other type or brand
of VFD when replacing the VFD.
NNoottee:: Failure to set parameter 4-18 Current Limit on a
field replacement VFD will not allow the
compressor to start and result in A18 Start Failed
or A49 Speed Limit on the VFD.
To verify and/or set parameters in the Compressor
VFD:
1. Press QQuuiicckk MMeennuu.
2. Press MMyy PPeerrssoonnaall MMeennuu.
3. Navigate through the options using the UUpp and
DDoowwnn arrows to parameter.
4. Adjust the value as shown in .
5. Press [OK].
SSeerrvviiccee aanndd MMaaiinntteennaannccee
To Next Page
