58
RT-SVX072A-EN
Table 24. Electrical service sizing data — dual DDP supply fan motors WITHOUT bypass option — 60 to 75 tons
200 V 230 V 460 V 575 V
MOC MOC MOC MOC
Motor Horsepower 2x Supply Fan Motors (4 pole)
2x 7.5HP 41.5 35.6 17.8 14.2
2x 10HP 53.6 45.8 22.9 18.4
2x 15HP 78.2 65.5 32.7 27.3
2x 20HP
N/A N/A
44.9 35.5
2x 25HP
N/A N/A
55.5 45.1
Motor Horsepower 2x Supply Fan Motors (6 pole)
2x 5HP 30.9 26.9 13.5 10.2
2x 7.5HP 45.5 40.0 20.0 16.4
2x 10HP 58.2 52.0 26.0 21.6
2x 15HP 85.5 74.5 37.3 29.6
Notes:
1. MOC (Max Operating Current) is VFD Input Current when fan motors are
operating at FLA
2. MOC for dual DDP supply fans without bypass represents the total VFD input
current for both supply fan motors.
3. Dual DDP fans selected under 1,700 RPM will have 6-pole motors
Table 25. Electrical service sizing data —electric heat module (electric heat units only) — 20 to 130 tons
Module
kW
Electric Heat FLA
200V 230V 460V 575V
30 83.3 72.2 36.1 28.9
50 138.8 120.3 60.1 48.1
70 194.3 168.4 84.2 67.4
90 249.8 216.5 108.3 86.6
110 305.3 264.6 132.3 105.9
130 - - 156.4 125.1
150 - - 180.4 144.3
170 - - 204.5 163.6
190 - - 228.5 182.8
Note: Electric heat FLA are determined at 208, 240, 480 and 600
volts.
Table 26. Voltage utilization range
Unit Voltage Voltage Utilization Range
200/60/3 180-220
230/60/3 207-253
460/60/3 414-506
575/60/3
517-633
Field Installed Control Wiring
The IntelliPak rooftop has many operating modes. The
flexibility of having several system modes depends
upon the type of sensor and/or remote panel selected
to interface with the Symbio 800. An overall layout of
the various control options available for a Single Zone
application, with the required number of conductors for
each device, is illustrated beginning with . Figure 32, p.
52 illustrates the various control options with the
required number of conductors for a Variable Air
Volume application.
NNoottee:: All field wiring must conform to NEC guidelines
as well as state and local codes.
WWAARRNNIINNGG
HHaazzaarrddoouuss VVoollttaaggee!!
FFaaiilluurree ttoo ddiissccoonnnneecctt ppoowweerr bbeeffoorree sseerrvviicciinngg ccoouulldd
rreessuulltt iinn ddeeaatthh oorr sseerriioouuss iinnjjuurryy..
DDiissccoonnnneecctt aallll eelleeccttrriicc ppoowweerr,, iinncclluuddiinngg rreemmoottee
ddiissccoonnnneeccttss bbeeffoorree sseerrvviicciinngg.. FFoollllooww pprrooppeerr
lloocckkoouutt//ttaaggoouutt pprroocceedduurreess ttoo eennssuurree tthhee ppoowweerr
ccaann nnoott bbee iinnaaddvveerrtteennttllyy eenneerrggiizzeedd.. VVeerriiffyy tthhaatt nnoo
ppoowweerr iiss pprreesseenntt wwiitthh aa vvoollttmmeetteerr..
IInnssttaallllaattiioonn
