Weights
Table 11. Air-cooled condenser - approximate operating weights (lbs.)
Unit
Without Exhaust Fan With Exhaust Fan
SA SX SE SF SL SS SA SX SE SF SL SS
20 4599 4919 5184 5439 5309 5473 4897 5217 5482 5737 5607 5771
25 4602 4922 5187 5442 5312 5576 4906 5226 5491 5746 5616 5880
30 5035 5381 5646 5901 5771 5933 5492 5838 6103 6358 6228 6390
40 7130 7485 7810 8200 8020 7700 7800 8155 8480 8870 8690 8370
50 7554 8004 8329 8719 8539 8270 8273 8723 9048 9438 9258 8989
55 7560 8004 8329 8719 8539 8270 8279 8723 9048 9438 9258 8989
60 8835 9481 9806 10296 10291 10464 9778 10424 10749 11239 11234 11407
70 9018 9663 9988 10478 10473 10646 9961 10606 10931 11421 11416 11589
75 9350 9999 10324 10814 10809 10982 10293 10942 11267 11757 11752 11925
90 X 13167 13322 13967 14042 14017 X 14505 14660 15305 15380 15355
105 X 13800 13955 14600 14675 14650 X 15138 15293 15938 16013 15988
115 X 14004 14159 14804 14879 14854 X 15342 15497 16142 16217 16192
130 X 14942 14445 15090 15165 15140 X 16280 15783 16428 16503 16478
Notes:
1. Weights shown are for air-cooled units with standard efficiency and include the following features: FC fans, Supply Fan VFD, standard
scroll compressors, 100% economizer, throwaway filters, maximum motor sizes, 460V XL start, high capacity heat, and access doors.
2. Weights shown represent approximate operating weights and have a ±10% accuracy. To calculate weight for a specific unit
configuration, utilize TOPSS™ or contact the local Trane® sales representative. ACTUAL WEIGHTS ARE STAMPED ON THE UNIT
NAMEPLATE.
