18
RT-SVX072A-EN
Figure 1. Unit dimensions, SAH_ cooling only units (20 to 75 ton)
NNoottee:: Use the table that follows.
C
B
D
A
J
E
H1
F2*
L
K
F1
H2**
G
M
Note: Ultra Low Leak Power Exhaust
Damper extends 0.65" beyond lifting lugs
*Condensate drain at F2 not used on DDP fans.
**Lifting lug at H2 not used on 20-36 T units.
100% MODULATNG
RELIEF DAMPER
100% MODULATNG
RELIEF DAMPER
1" NPT CONDENSATE
DRAIN CONNECTION (BOTH SIDES)
FILTER
ACCESS
SUPPLY
FAN
ACCESS
COMPRESSOR
ACCESS
FLUE VENT
(GAS HEAT ONLY)
HEATER ACESS
1 1/4" NPT GAS
PIPE ENTRY WITH
GROMMET
DRAIN HOLE
CPVC FURNACE DRAIN
(SEE CPVC DIMENSIONAL TABLE)
CONTROL BOX
ACCESS
FRESH AIR INTAKE
(DIMENSION MEASURED
FROM BOTTOM OF
BASE RAIL TO TOP
OF FAN GRILL)
Table 3. Unit dimensions, SAH_ cooling only units (20 to 75 ton)
Nom.
Tons
A B C D E F1 F2 G H1 H2 J
20, 25
21'–9 3/4"
6'–9"
7'–6 1/2" 7'–3 1/4" 3'–9 5/16"
10'–7" 12'–6" 1" 7'
N/A 1'–3 1/2"
30
21'–9 3/4"
6'–9"
7'–6 1/2" 7'–3 1/4" 4'–9 5/16"
10'–7" 12'–6" 1" 7'
N/A 1'–3 1/2"
40 29'–8" 6'–9"
7'–6 1/2" 7'–3 1/4" 5'–9 5/16" 12'–1 1/4" 15'–4 5/16"
1" 8'
16'–2 5/16"
2'–5"
50, 55
29'–8" 6'–9"
7'–6 1/2" 7'–3 1/4" 6'–9 5/16" 12'–1 1/4" 15'–4 5/16"
1" 8'
16'–2 5/16"
2'–5"
60 29'–8" 6'–9" 9'–8"
7'–3 1/4" 5'–9 5/16" 12'–1 1/4" 15'–4 5/16"
1" 8'
16'–2 5/16"
2'–5"
70, 75
29'–8" 6'–9" 9'–8"
7'–3 1/4" 5'–9 5/16" 12'–1 1/4" 15'–4 5/16"
1" 8'
16'–2 5/16"
2'–5"
DDiimmeennssiioonnaall DDaattaa
