RT-SVX072A-EN
37
Figure 16. Removing supply and relief fan assembly shipping hardware (20 to 75 ton)
Rubber Isolator Locations
ISO-2
ISO-2
ISO-5
ISO-4
ISO-4
ISO-3
ISO-3
ISO-1
Spring Isolator Locations
Fan Assembly Rail
Unit Base Rail
Ground Strap
(Do Not Remove)
Shipping Channel
Shipping Channel
1/2” - Tie Down Bolt
1/2” - Flat Washer
TOP VIEW
DETAIL “A”
4 Locations
Right End View
IInnssttaallllaattiioonn
