48
RT-SVX072A-EN
Figure 26. Hot water piping (20 to 75 ton)
3-Way Modulating Valve
(Field Installed)
Return
Water
Supply
Wa
ter
Gate Valves
Bypass
Air Vent
A AB
B
Hot Water Coil
(ARI Listed)
OUTLET
INLET
Pressure Drop
Balancing Globe
Valve
Strainer
Figure 27. Hot water piping (90 to 130 ton)
Air Vent
Hot Water Coil
(ARI Listed)
Hot Water Coil
(ARI Listed)
Return
Water
Bypass
INLET
INLET
OUTLET
OUTLET
Strainer
Supply
Water
Pressure Drop
Balancing Globe
Valve
A AB
B
3-Way Modulating Valve
(Field Installed)
IInnssttaallllaattiioonn
