Trane IntelliPak CGAF Series User Manual

13
General Information
Factory Presets (Continued)
Factory Preset Changed See page... To adjust
To to adjust Press....
Ice Building Control Fuctions
Ice Building Function Disabled 26 SETUP
Ice Building Mode One Time 26 SETUP
Ice Rebuild Delay Time 360 Minutes 26 SETUP
GBAS 0-5 VDC Module I/O Assignments
GBAS (0-5 VDC) Analog Input 1 Assignment Not Assigned 27 SETUP
GBAS (0-5 VDC) Analog Input 2 Assignment Not Assigned 27 SETUP
GBAS (0-5 VDC) Analog Input 3 Assignment Not Assigned 27 SETUP
GBAS (0-5 VDC) Analog Input 4 Assignment Not Assigned 27 SETUP
GBAS (0-5 VDC) Binary Output 1 Definition Indicate any comp
is running 28 SETUP
GBAS 0-5 V Output 1 Alarm Assignments Any active diagnostic 28 SETUP
GBAS (0-5 VDC) Binary Output 2 Definition Indicate selected
diagnostics 29 SETUP
GBAS 0-5 V Output 2 Alarm Assignments Comp protection LPC
Open Ckt 1 29 SETUP
Comp protection LPC
Open Ckt 2 (40-60 Ton) 29 SETUP
Compressor Trip Ckt 1 29 SETUP
Compressor Trip Ckt 2
(40 - 60 Ton) 29 SETUP
Comp Contactor Fail Ckt 1 29 SETUP
Comp Contactor Fail Ckt 2
(40 - 60 Ton) 29 SETUP
Low Press Control
Open - Ckt 1 29 SETUP
Low Press Control
Open - Ckt 2 (40-60 Ton) 29 SETUP
GBAS (0-5 VDC) Binary Output 3 Definition Indicate Unit at
Max capacity 29 SETUP
GBAS (0-5 VDC) Output 3 Alarm Assignments Any active diagnostic 29 SETUP
GBAS (0-5 VDC) Binary Output 4 Definition Indicate selected
diag alarms 29 SETUP
GBAS (0-5 VDC) Output 4 Alarm Assignments Any active diagnostic 29 SETUP
GBAS (0-5 VDC) Binary Output 5 Definition Indicate selected
diag alarms 29 SETUP
GBAS (0-5 VDC) Output 5 Alarm Assignments Any active diagnostic 29 SETUP
GBAS 0-10 VDC Module I/O Assignments
GBAS (0-10 VDC) Analog Input 1 Assignment Not Assigned 29 SETUP
GBAS (0-10 VDC) Analog Input 2 Assignment Not Assigned 29 SETUP
GBAS (0-10 VDC) Analog Input 3 Assignment Not Assigned 29 SETUP
GBAS (0-10 VDC) Analog Input 4 Assignment Not Assigned 29 SETUP
GBAS (0-10 VDC) Binary Output Definition Indicate selected
diag alarms 29 SETUP
GBAS (0-10 VDC) Output Alarm Assignments Any active diagnostic 30 SETUP
GBAS (0-10 VDC) Analog Output 1 Assignment Leaving solution temp 30 SETUP
GBAS (0-10 VDC) Analog Output 2 Assignment Entering solution temp 30 SETUP
GBAS (0-10 VDC) Analog Output 3 Assignment Active cooling capacity 30 SETUP
GBAS (0-10 VDC) Analog Output 4 Assignment Outside air temperature 30 SETUP
CGM alarm output definitions
Any Active Diagnostic 30 SETUP
