General Information
Factory Presets (Continued)
Factory Preset Changed See page... To adjust
To to adjust Press....
Actuator Setup Definitions
Number 1 Low Ambient Maximum Stroke 30 seconds 31 SETUP
Number 1 Low Ambient Minimum Voltage 2.0v 31 SETUP
Number 1 Low Ambient Maximum Voltage 10.0v 31 SETUP
Number 1 Low Ambient Acting Direct 31 SETUP
Number 2 Low Ambient Maximum Stroke 30 seconds 31 SETUP
Number 2 Low Ambient Minimum Voltage 2.0v 31 SETUP
Number 2 Low Ambient Maximum Voltage 10.0v 31 SETUP
Number 2 Low Ambient Acting Direct 31 SETUP
Ckt 1 Suction Line Pressure Transducer --
voltage at 0 PSIG 0.118 V 32 SETUP
Ckt 1 Suction Line Pressure Transducer --
voltage at 100 PSIG 4.847 V 32 SETUP
Ckt 2 Suction Line Pressure Transducer --
voltage at 0 PSIG 0.118 V 32 SETUP
Ckt 2 Suction Line Pressure Transducer --
voltage at 100 PSIG 4.847 V 32 SETUP
Ckt 1 Liquid Line Pressure Transducer --
voltage at 0 PSIG 0.118 V 32 SETUP
Ckt 1 Liquid Line Pressure Transducer --
voltage at 400 PSIG 4.847 V 32 SETUP
Ckt 2 Liquid Line Pressure Transducer --
voltage at 0 PSIG 0.118 V 32 SETUP
Ckt 2 Liquid Line Pressure Transducer --
voltage at 400 PSIG 4.847 V 32 SETUP
Head Pressure Control Setup
Saturated condenser Temp Control Band
(Lower Limit) 85 deg F 26 SETUP
Saturated condenser Temp Control Band
(Upper Limit) 125 deg F 26 SETUP
Saturated condenser Temp Control Band
(Temporary Low Limit Suppression) 10 deg F 27 SETUP
Saturated condenser Temp
(Efficiency Check Point) 110 deg F 27 SETUP
Saturated condenser Temp (Low Ambient
Control Point) 100 deg F 27 SETUP
S
aturated condenser Temp (Low Ambient
C
ontrol Deadband)
4.0 deg F 27 SETUP
Saturated condenser Temp (OA Temp
Suppression Setpoint)
40 deg F 27 SETUP
