RT-SVP04F-EN 109
System Testing & Troubleshooting
Humidification Relay ON Used With: All units with RTM,
MCM, and HI.
Possible Values: ON, OFF
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key to advance the cursor.
4. Repeat steps 1 and 2 for the next value.
5. Press the NEXT key until the following screen is displayed
(if applicable).
Note: Humidification Relay can only be set ON if Supply Fan
Output is set ON. A message will display indicating such and
operation will be prevented
Energy Recovery Control Submenu Used With: All IntelliPak II units
with Energy Recovery installed
Press ENTER to Review or Adjust
1. Pressing the NEXT key will bypass this section.
Energy Recovery Wheel Operation: OFF Used With: All IntelliPak II units
with Energy Recovery installed
Factory Preset: Wheel Operation:
OFF; Preheat Relay: OFF
Possible Values: ON, OFF
Energy Recovery Preheat Relay: OFF
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key to advance the cursor.
4. Repeat steps 1 and 2 for the next value.
5. Press the NEXT key until the following screen is displayed
(if applicable).
Note: Attempting to set the ER Preheat relay to the ON state
without the Supply Fan Output being in the ON state first will
generate an informational message and the operation will
be prevented.
Exhaust Air Bypass Damper Pos: 0% Used With: All IntelliPak II units
with Energy Recovery installed
Factory Preset: 0%
Possible Values: 100%
Outside Air Bypass Damper Pos: 0%
1. Press the + or - key until the proper value is displayed.
2. Press the ENTER key to confirm this choice.
3. Press the NEXT key to advance the cursor.
4. Repeat steps 1 and 2 for the next value.
5. Press the NEXT key until the following screen is displayed
(if applicable).
