Trane IntelliPak I User Manual

38 RT-SVP04F-EN
System Operating Status
Return Plenum Pressure Target: 0.8 IWC Used With: All units with Return
Fan installed.
Possible Values: 0.1 to 2.5 IWC;
Return Fan VFD= Opening to/Closing
to 0 to 100%
Return Fan VFD Pos: Opening to 45%
1. Pressing the NEXT key will scroll forward through the screens.
2. Pressing the PREVIOUS key will scroll backwards to view the
previously displayed screen.
3. Press the + (Plus) key while viewing any screen to add that
screen to the custom menu. Refer to the custom menu for the
creation and maintenance of customized menus.
4. Press the NEXT key until the following screen is displayed.
(if applicable)
Max Return Plenum Pressure Stp: 1.2 IWC Used With: All units with Return
Fan installed.
Possible Values: Max Return= 0.1
to 2.5 IWC (Default 1.2 IWC);
Deadband = 0.1 to 1.0 IWC (Default
0.2 IWC)
Note: High limit is 3.5 IWC and is not
adjustable.
High Limit: 3.5 IWC Deadband: 0.2 IWC
1. Pressing the NEXT key will scroll forward through the screens.
2. Pressing the PREVIOUS key will scroll backwards to view the
previously displayed screen.
3. Press the + (Plus) key while viewing any screen to add that
screen to the custom menu. Refer to the custom menu for the
creation and maintenance of customized menus.
4. Press the NEXT key until the following screen is displayed.
(if applicable)
End of Submenu (NEXT) to Enter STATUS
1. Press the NEXT key to leave the submenu and show following
screen.
2. Press PREVIOUS to page back through the submenu.
Energy Recovery Status Submenu Used With: All IntelliPak II units
with Energy Recovery installed.
Press ENTER to View Data in This Submenu
1. Pressing the NEXT key will bypass this section.
Energy Wheel Relay: ON Used With: All IntelliPak II units
with Energy Recovery installed.
Possible Values: ON, OFF
Energy Wheel Proving: ON
1. Pressing the NEXT key will scroll forward through the screens.
2. Pressing the PREVIOUS key will scroll backwards to view the
previously displayed screen.
3. Press the + (Plus) key while viewing any screen to add that
screen to the custom menu. Refer to the custom menu for the
creation and maintenance of customized menus.
4. Press the NEXT key until the following screen is displayed.
(if applicable)
