Trane RTHD - Power Supply Module; Power Supply Troubleshooting and Specifications

Dimensions
14 SO-SVN048A-EN
Figure 7. D2 drive, 4 conduit, 460 and 575V, 186 to 336 amps - rotated drive orientation
8.79
1.67
58.80
24.68
16.54
14.62
10.25
13.50
20.50
23.75
3.44
5.00
3.19
14.09
3.08
