Trane RTHD

Dimensions
SO-SVN048A-EN 15
Drive Dimensions
Figure 8. D1 drive dimensions - sheet 1 of 2
33.2
7.12.9
2.5 7.9
.9
14.5
12.8
33.4
35.2
26.1
12.0
6.6
GLAND PLATE
Figure 9. D1 drive dimensions - sheet 2 of 2
4.0
0
GROUND 3.14
0
7.55
1.28
0
R 2.44
S 3.99
T 5.53
GROUND 6.40
U 7.27
V 8.81
W 10.35
11.52
4.78
0
GROUND3.14
MAINS
TERMINALS
MOTOR
TERMINALS
