Trane RTHD

Dimensions
16 SO-SVN048A-EN
Figure 10. D2 drive dimensions - sheet 1 of 2
16.54
43.28
41.42
34.25
14.51
2.76 11.02
10.672.94
41.36
.94
4X .43
15.7
6.9
GLAND PLATE
Figure 11. D2 drive dimensions - sheet 2 of 2
GROUND 6.00
0
GROUND 7.00
13.00
2.00
0
R 3.00
S 5.00
T 7.00
U 10.00
V 12.00
W 14.00
15.0
4.51
0
3.51
0
GROUND6.00
GROUND7.00
MAINS
TERMINALS
MOTOR
TERMINALS
