Trane RTHD

Pre-Installation
20 SO-SVN048A-EN
Table 3. Components – remote mount 460 volts
Kit Part
Number Mnemonic Part Number Description QTY Package Label
Serviceable
Component
Remote Mount Components
127500050001
RNG02318 X13640734010 Choke Core 5
531405110100 Core Support Bracket 1
531405470100 Buss Bar, Formed (for motor connection) 2
531405480100 Buss Bar, Straight (for motor connection) 1
X13650733060 Dual Relay output Ref 1A8 (latest revision) 1
BRD02944 X19220085030 Housing; 4 Circuit Term (Phoenix connector) for 1A8 2
HLD00579 X13260721020 Relay, 4PDT, 120VAC, 8amps 2 1K14, 1K15 Relays
RAL01142 X13260722010 Relay Socket, 4PDT, Din rail mount 2
X13500224207 Din rail 4-inch 2
X13491363010 Din Rail End Stop 4
SO-SVN048*-EN KIT IOM (supplied by Trane) 1
507117830001 Schematics Printed on mylar 1
BAS-SVX54*-EN Drive IOM 1
507118200001 AFD Label 1
507118300001 Motor Terminal Shield 1
X39003759010 Label, Technical support 1
VFD DRIVE (one only)
127500110001 X13171807001
AFD DRIVE, 460V, IP21, 110KW,134X2754,
TR-200N110T4E21H2TGC7XXSXXXXAXBXCXXXXDX
Y
127500120001 X13171807002
AFD DRIVE, 460V, IP21, 132KW, 134X2755,
TR-200N132T4E21H2TGC7XXSXXXXAXBXCXXXXDX
Y
127500130001 X13171807003
AFD DRIVE, 460V, IP21, 160KW, 134X2756,
TR-200N160T4E21H2TGC7XXSXXXXAXBXCXXXXDX
Y
127500140001 X13171807004
AFD DRIVE, 460V, IP21, 200KW, 134X2757,
TR-200N200T4E21H2TGC7XXSXXXXAXBXCXXXXDX
Y
127500150001 X13171807005
AFD DRIVE, 460V, IP21, 250KW, 134X2758,
TR-200N250T4E21H2TGC7XXSXXXXAXBXCXXXXDX
Y
127500160001 X13171807006
AFD DRIVE, 460V, IP21, 315KW, 134X2759,
TR-200N315T4E21H2TGC7XXSXXXXAXBXCXXXXDX
Y
CONTROLS (one only)
NONE - UC800 Only for customers with existing UC800 controls
18800260100 UC800/TD7 upgrade Kit with arm
18800270100 UC800/TD7 upgrade Kit without arm
OPTIONAL PEDESTAL
507117990001 Optional AFD Drive Pedestal D1H Below 334 Amps 1
Drive Mount hardware
- (label nuts and
screws only)
507118180001 Optional AFD Drive Pedestal D2H 335 Amps - 455 Amps 1
Drive Mount hardware
- (label nuts and
screws only)
