Trane RTHD

Pre-Installation
SO-SVN048A-EN 21
Table 4. Components – close mount 575 volts
Kit Part Number Mnemonic Part Number Description QTY
Close Mount Components
127500060001
RNG02318 X13640734010 Choke Core M-116 5
531405110100 Core Support Bracket 1
531405470100 Buss Bar, Formed (for motor connection) 2
531405480100 Buss Bar, Straight (for motor connection) 1
BRD02944 X13650733060 Dual Relay output Ref 1A8 (latest revision) 1
HLD00579 X13260721020 Relay, 4PDT, 120VAC, 8amps 2
RAL01142 X13260722010 Relay Socket, 4PDT, Din rail mount 2
X13500224070 Din rail 4-inch 1
X13491363010 Din Rail End Stop 4
507117910001 Strut Channel, 1.625-inch x 1.625-inch x 5ft (black color) 1
507117920001 Strut Channel Base, 4-inch x 6-inch (black color) 1
507117930001 Strut Channel L Bracket 1
507117960001 .75-inch conduit connector 90 degree 1
507117970001 .75-inch Conduit Connector Straight 1
X19080029040 0.75-inch Conduit - AFD/relay signal wires 20 ft
X19010309470 single conductor cable - 16awg UL 1230 blk 125 ft
CAB01534 X19051625030 Global harness Female to Amp connector 78.74-inch 1
CAB01153 X19051624030 Global harness Male to Amp connector 78.74-inch 1
CAB01150 X19051623020 Extension Harness - 78.74-inch 1
X39002507010 Label, Warning (AFD) 1
507117810001 Label, Nameplate 1
SO-SVN048*-EN KIT IOM (supplied by Trane) 1
507117830001 Schematics Printed on mylar 1
BAS-SVX54*-EN Drive IOM 1
507118200001 AFD Label 1
X39003759010 Label, Technical support 1
507118300001 Motor Terminal Shield 1
Conduit Kits
127500070001
2 Conduit Kit
X19038200000 Connector, 2-inch conduit 4
X19120032060 2-inch conduit Sleeve 4
507118010001 PWR WIRE ASSEMBLY D1- B 1
507118030001 PWR WIRE ASSEMBLY D1- D 1
507118080001 Modified pedestal plate (Dwg provided) 1
507117990001 AFD Drive Pedestal D1H 1
127500080001
4 Conduit Kit
(large base)
X19038200000 Connector, 2-inch conduit 8
X19120032060 2-inch conduit Sleeve 8
507118040001 PWR WIRE ASSEMBLY D2- A 1
507118050001 PWR WIRE ASSEMBLY D2 -B 1
507118060001 PWR WIRE ASSEMBLY D2 -C 1
507118070001 PWR WIRE ASSEMBLY D2 -D 1
507118110001 Modified pedestal plate (Dwg provided) 1
507118180001 AFD Drive Pedestal D2H 1
VFD DRIVE (one only)
127500170001 X13171808001
AFD DRIVE, 600V, IP21, 110KW, 134X2760,
TR-200N110T7E21H2TGC7XXSXXXXAXBXCXXXXDX
127500180001 X13171808002
AFD DRIVE, 600V, IP21, 132KW, 134X2761,
TR-200N132T7E21H2TGC7XXSXXXXAXBXCXXXXDX
