Installation
SO-SVN048A-EN 41
6. Install pedestal adaptor plate to the pedestal.
7. Install the power wire conduits to the strut channel using
supplied brackets.
Figure 49. Modbus
®
cable and control power mounting
Figure 50. Conduit connector assembly
Figure 51. Adaptor plate assembly
Figure 52. Power wire conduit mounting
