Trane S9V2B040U3VSBB - Page 19

S9V2-VS-SVX001-1D-EN
19
Table 6. S9V2B040U3VS and S9V2B040D3VS Cooling Airflow
S9V2B040U3VS and S9V2B040D3VS Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with
Filter (iwc)
Outdoor
Tonnage -
"Odt" (tons)
Airflow
Setting -
(CFM/ton)
EXTERNAL STATIC PRESSURE (IN. W. C.)
0.1 0.3 0.5 0.7 0.9
1.5
450
CFM / WATTS
675 / 47 675 / 81 675 / 121 675 / 166 675 / 215
420
CFM / WATTS
630 / 40 630 / 72 630 / 111 630 / 154 630 / 202
400
CFM / WATTS 600 / 36 600 / 67 600 / 105 600 / 147 600 / 193
370
CFM / WATTS
555 / 30 555 / 60 555 / 96 555 / 136 555 / 181
350
CFM / WATTS
525 / 27 525 / 56 525 / 90 525 / 130 525 / 174
330
CFM / WATTS
495 / 24 495 / 51 495 / 85 495 / 124 495 / 167
310
CFM / WATTS
465 / 21 465 / 48 465 / 80 465 / 118 465 / 161
290
CFM / WATTS 435 / 19 435 / 44 435 / 76 435 / 113 435 / 155
2.0
450
CFM / WATTS
900 / 94 900 / 137 900 / 186 900 / 240 900 / 298
420
CFM / WATTS
840 / 79 840 / 120 840 / 166 840 / 218 840 / 273
400
CFM / WATTS
800 / 70 800 / 109 800 / 154 800 / 204 800 / 258
370
CFM / WATTS
740 / 58 740 / 95 740 / 138 740 / 185 740 / 236
350
CFM / WATTS 700 / 51 700 / 86 700 / 127 700 / 173 700 / 223
330
CFM / WATTS
660 / 44 660 / 78 660 / 118 660 / 162 660 / 211
310
CFM / WATTS
620 / 38 620 / 71 620 / 109 620 / 152 620 / 199
290
CFM / WATTS
580 / 33 580 / 64 580 / 101 580 / 142 580 / 188
2.5
450
CFM / WATTS
1125 / 167 1125 / 219 1125 / 278 1125 / 341 1125 / 408
420
CFM / WATTS 1050 / 139 1050 / 188 1050 / 244 1050 / 304 1050 / 368
400
CFM / WATTS
1000 / 123 1000 / 170 1000 / 223 1000 / 281 1000 / 343
370
CFM / WATTS
925 / 100 925 / 145 925 / 195 925 / 250 925 / 308
350
CFM / WATTS
875 / 87 875 / 129 875 / 178 875 / 230 875 / 287
330
CFM / WATTS
825 / 121 825 / 160 825 / 205 825 / 254 825 / 308
310
CFM / WATTS 775 / 101 775 / 139 775 / 182 775 / 229 775 / 281
290
CFM / WATTS
725 / 88 725 / 123 725 / 164 725 / 210 725 / 260
3.0
(a)
450
CFM / WATTS
1350 / 272 1350 / 334 1350 / 402 1298 / 440 1198 / 450
420
CFM / WATTS
1260 / 226 1260 / 284 1260 / 348 1260 / 417 1198 / 450
400
CFM / WATTS
1200 / 198 1200 / 254 1200 / 315 1200 / 381 1198 / 450
370
CFM / WATTS 1110 / 161 1110 / 213 1110 / 271 1110 / 333 1110 / 399
350
(a)
CFM / WATTS
1050 / 139 1050 / 188 1050 / 244 1050 / 304 1050 / 368
330
CFM / WATTS
990 / 119 990 / 166 990 / 219 990 / 277 990 / 338
310
CFM / WATTS
930 / 102 930 / 146 930 / 197 930 / 252 930 / 311
290
CFM / WATTS
870 / 86 870 / 128 870 / 176 870 / 229 870 / 285
Table 7. S9V2B060D3VS Heating Airflow
S9V2B060D3VS Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 38,500
2nd Stage Capacity = 58,200
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 711
CFM
636 649 662 675 688
Temp. Rise 55 53 52 51 50
Watts
49 86 124 161 199
Medium Low
(a)
814
CFM
732 740 748 756 764
Temp. Rise 47 47 47 46 46
Watts
65 105 146 186 226
Medium 893
CFM
817 820 823 826 828
Temp. Rise 42 42 42 42 42
Watts
82 123 164 206 247
High
1067
CFM
969 962 956 950 944
Temp. Rise 36 36 36 37 37
Watts
126 170 214 258 302
Heating 2nd
Stage
Low 900
CFM
836 840 844 848 852
Temp. Rise 64 64 63 63 62
Watts
79 126 173 219 266
Medium Low
(a)
1030
CFM
951 955 959 963 967
Temp. Rise 56 56 56 55 55
Watts
112 163 213 264 314
Medium 1130
CFM
1051 1052 1054 1055 1056
Temp. Rise 51 51 51 51 51
Watts
145 197 249 301 352
High
1350
CFM
1251 1238 1225 1212 1199
Temp. Rise 43 43 44 44 45
Watts
236 291 347 402 458
HHeeaattiinngg aanndd CCoooolliinngg AAiirrffllooww TTaabblleess
