Table 20. S9V2D120D5VS Heating Airflow
S9V2D120D5VS Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 76,700
2nd Stage Capacity = 116,350
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 1260
CFM
1194 1195 1196 1197 1198
Temp. Rise 59 59 59 59 59
Watts
139 191 243 295 347
Medium Low 1332
CFM
1271 1280 1289 1298 1307
Temp. Rise 56 55 55 54 54
Watts
160 214 268 322 376
Medium 1404
CFM
1329 1331 1332 1334 1335
Temp. Rise 53 53 53 53 54
Watts
183 238 293 348 404
High
(a)
1620
CFM
1515 1560 1605 1649 1694
Temp. Rise 46 45 45 44 43
Watts
258 330 403 476 549
Heating 2nd
Stage
Low 1750
CFM
1716 1715 1714 1714 1713
Temp. Rise 63 63 63 63 63
Watts
318 396 473 551 628
Medium Low 1850
CFM
1814 1818 1823 1827 1831
Temp. Rise 59 59 59 59 59
Watts
374 453 533 612 691
Medium 1950
CFM
1917 1904 1891 1877 1864
Temp. Rise 56 57 57 57 58
Watts
434 514 595 676 756
High
(a)
2250
CFM
2130 2140 2151 2162 2172
Temp. Rise 51 50 50 50 49
Watts
628 725 822 919 1016
Table 21. S9V2D120U5VS and S9V2D120D5VS Cooling Airflow
S9V2D120U5VS and S9V2D120D5VS Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with
Filter (iwc)
Outdoor
Tonnage -
"Odt" (tons)
Airflow
Setting -
(CFM/ton)
EXTERNAL STATIC PRESSURE (IN. W. C.)
0.1 0.3 0.5 0.7 0.9
3.0
450
CFM / WATTS
1336 / 163 1346 / 221 1354 / 281 1360 / 341 1363 / 402
420
CFM / WATTS
1248 / 137 1258 / 191 1265 / 247 1271 / 304 1274 / 361
400
CFM / WATTS 1189 / 121 1199 / 173 1206 / 227 1211 / 281 1214 / 336
370
CFM / WATTS
1102 / 100 1110 / 148 1116 / 198 1121 / 249 1123 / 301
350
CFM / WATTS
1043 / 87 1051 / 133 1057 / 181 1060 / 230 1062 / 279
330
CFM / WATTS
985 / 76 991 / 119 996 / 165 999 / 211 1000 / 259
310
CFM / WATTS
927 / 65 932 / 107 936 / 150 937 / 195 938 / 241
290
CFM / WATTS 869 / 56 872 / 95 874 / 136 875 / 179 875 / 223
3.5
450
CFM / WATTS
1559 / 244 1567 / 312 1574 / 381 1579 / 450 1583 / 519
420
CFM / WATTS
1455 / 204 1464 / 267 1472 / 331 1477 / 396 1481 / 462
400
CFM / WATTS
1386 / 179 1395 / 240 1403 / 301 1409 / 363 1413 / 426
370
CFM / WATTS
1282 / 147 1292 / 203 1300 / 260 1305 / 318 1309 / 376
350
CFM / WATTS 1214 / 127 1223 / 181 1231 / 235 1236 / 290 1239 / 346
330
CFM / WATTS
1145 / 110 1154 / 160 1161 / 212 1166 / 265 1169 / 318
310
CFM / WATTS
1077 / 94 1085 / 142 1092 / 191 1096 / 241 1098 / 292
290
CFM / WATTS
1009 / 80 1016 / 125 1021 / 171 1025 / 219 1026 / 267
4.0
450
CFM / WATTS
1783 / 350 1789 / 427 1793 / 505 1796 / 584 1798 / 663
420
CFM / WATTS 1663 / 290 1671 / 362 1677 / 436 1681 / 509 1683 / 583
400
CFM / WATTS
1584 / 255 1592 / 324 1599 / 393 1603 / 464 1607 / 534
370
CFM / WATTS
1465 / 207 1474 / 271 1481 / 336 1487 / 401 1491 / 467
350
CFM / WATTS
1386 / 179 1395 / 240 1403 / 301 1409 / 363 1413 / 426
330
CFM / WATTS
1307 / 154 1317 / 211 1324 / 269 1330 / 328 1334 / 388
310
CFM / WATTS 1228 / 131 1238 / 185 1246 / 240 1251 / 296 1254 / 352
290
CFM / WATTS
1150 / 111 1159 / 162 1166 / 214 1171 / 266 1174 / 320
5.0
(a)
450
CFM / WATTS
2238 / 646 2235 / 742 2230 / 840 2226 / 938 2220 / 1036
420
CFM / WATTS
2086 / 533 2086 / 623 2085 / 714 2083 / 806 2080 / 897
400
CFM / WATTS
1985 / 466 1987 / 552 1988 / 639 1988 / 726 1986 / 813
370
CFM / WATTS 1834 / 377 1838 / 456 1842 / 536 1844 / 617 1845 / 698
350
(a)
CFM / WATTS
1733 / 324 1740 / 399 1745 / 475 1748 / 552 1750 / 628
330
CFM / WATTS
1633 / 277 1641 / 347 1647 / 419 1652 / 492 1655 / 564
310
CFM / WATTS
1534 / 234 1543 / 301 1550 / 369 1555 / 437 1558 / 505
290
CFM / WATTS
1435 / 196 1444 / 259 1452 / 322 1458 / 387 1461 / 451
(a)
Factory Setting.
