S9V2-VS-SVX001-1D-EN
25
Table 18. S9V2C100U5VS and S9V2C100D5VS Cooling Airflow
S9V2C100U5VS and S9V2C100D5VS Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with
Filter (iwc)
Outdoor
Tonnage -
"Odt" (tons)
Airflow
Setting -
(CFM/ton)
EXTERNAL STATIC PRESSURE (IN. W. C.)
0.1 0.3 0.5 0.7 0.9
3.0
450
CFM / WATTS
1378 / 178 1376 / 234 1374 / 292 1372 / 352 1368 / 413
420
CFM / WATTS
1289 / 149 1286 / 201 1284 / 256 1282 / 312 1277 / 371
400
CFM / WATTS 1228 / 131 1225 / 181 1223 / 234 1221 / 288 1217 / 345
370
CFM / WATTS
1138 / 108 1134 / 154 1132 / 203 1130 / 255 1125 / 309
350
CFM / WATTS
1077 / 94 1073 / 138 1071 / 185 1068 / 235 1064 / 287
330
CFM / WATTS
1016 / 81 1011 / 123 1009 / 168 1006 / 216 1002 / 266
310
CFM / WATTS
955 / 70 950 / 110 947 / 153 944 / 199 940 / 248
290
CFM / WATTS 894 / 59 888 / 97 885 / 138 882 / 183 877 / 231
3.5
450
CFM / WATTS
1601 / 269 1599 / 334 1597 / 401 1594 / 469 1590 / 539
420
CFM / WATTS
1498 / 224 1496 / 284 1494 / 347 1491 / 411 1487 / 477
400
CFM / WATTS
1428 / 196 1426 / 254 1424 / 314 1422 / 376 1417 / 439
370
CFM / WATTS
1324 / 160 1321 / 214 1319 / 270 1317 / 327 1313 / 387
350
CFM / WATTS 1253 / 138 1251 / 190 1249 / 243 1246 / 298 1242 / 355
330
CFM / WATTS
1183 / 119 1180 / 167 1178 / 218 1175 / 271 1171 / 326
310
CFM / WATTS
1112 / 102 1109 / 147 1107 / 196 1104 / 246 1100 / 299
290
CFM / WATTS
1041 / 86 1037 / 129 1035 / 175 1032 / 223 1028 / 275
4.0
450
CFM / WATTS
1820 / 388 1819 / 462 1816 / 538 1812 / 615 1807 / 693
420
CFM / WATTS 1704 / 321 1702 / 390 1700 / 461 1697 / 533 1692 / 607
400
CFM / WATTS
1626 / 281 1624 / 347 1622 / 415 1619 / 484 1614 / 554
370
CFM / WATTS
1507 / 228 1505 / 289 1504 / 352 1501 / 417 1497 / 482
350
CFM / WATTS
1428 / 196 1426 / 254 1424 / 314 1422 / 376 1417 / 439
330
CFM / WATTS
1348 / 168 1346 / 223 1344 / 280 1342 / 338 1338 / 399
310
CFM / WATTS 1268 / 143 1266 / 195 1264 / 248 1261 / 304 1257 / 362
290
CFM / WATTS
1188 / 120 1185 / 169 1183 / 220 1180 / 273 1176 / 328
5.0
(a)
450
CFM / WATTS
2249 / 722 2246 / 815 2241 / 909 2236 / 1004 2228 / 1101
420
CFM / WATTS
2108 / 595 2105 / 681 2101 / 770 2096 / 859 2090 / 949
400
CFM / WATTS
2013 / 519 2010 / 602 2007 / 685 2003 / 771 1997 / 857
370
CFM / WATTS 1869 / 418 1867 / 494 1864 / 572 1860 / 651 1855 / 731
350
(a)
CFM / WATTS
1772 / 359 1770 / 431 1768 / 505 1764 / 580 1759 / 656
330
CFM / WATTS
1675 / 305 1673 / 374 1671 / 443 1667 / 514 1663 / 587
310
CFM / WATTS
1576 / 258 1575 / 322 1573 / 388 1570 / 455 1565 / 523
290
CFM / WATTS
1478 / 216 1476 / 276 1474 / 337 1471 / 401 1467 / 466
Table 19. S9V2D120U5VS Heating Airflow
S9V2D120U5VS Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 77,050
2nd Stage Capacity = 116,250
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 1123
CFM
1138 1158 1178 1198 1218
Temp. Rise 61 60 59 58 57
Watts
115 176 236 297 358
Medium Low 1332
CFM
1371 1383 1394 1406 1417
Temp. Rise 51 50 50 49 49
Watts
182 251 320 389 457
Medium
(a)
1404
CFM
1440 1450 1461 1471 1482
Temp. Rise 48 48 48 47 47
Watts
208 283 357 431 505
High
1620
CFM
1669 1674 1680 1685 1691
Temp. Rise 42 42 41 41 41
Watts
315 388 460 533 605
Heating 2nd
Stage
Low 1560
CFM
1654 1637 1621 1604 1587
Temp. Rise 65 66 67 67 68
Watts
291 360 430 499 568
Medium Low 1850
CFM
1980 1951 1922 1893 1864
Temp. Rise 55 56 57 58 58
Watts
456 539 621 704 787
Medium
(a)
1950
CFM
2075 2037 1999 1961 1923
Temp. Rise 52 53 54 55 56
Watts
527 611 696 781 865
High
2250
CFM
2280 2197 2114 2032 1949
Temp. Rise 48 50 52 54 56
Watts
795 819 842 865 888
HHeeaattiinngg aanndd CCoooolliinngg AAiirrffllooww TTaabblleess
