Trane S9V2B040U3VSBB - Page 24

24
S9V2-VS-SVX001-1D-EN
Table 16. S9V2C100U5VS Heating Airflow
S9V2C100U5VS Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 63,800
2nd Stage Capacity = 97,650
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 1146
CFM
1183 1172 1161 1150 1138
Temp. Rise 50 50 51 51 52
Watts
141 197 253 310 366
Medium Low 1280
CFM
1300 1297 1294 1290 1287
Temp. Rise 45 45 45 46 46
Watts
185 245 306 366 426
Medium 1359
CFM
1425 1404 1384 1364 1343
Temp. Rise 41 42 42 43 43
Watts
214 276 338 400 462
High
(a)
1446
CFM
1454 1452 1450 1449 1447
Temp. Rise 40 40 40 41 41
Watts
257 321 386 451 515
Heating 2nd
Stage
Low 1450
CFM
1513 1507 1502 1497 1491
Temp. Rise 60 60 60 60 61
Watts
260 329 398 468 537
Medium Low 1620
CFM
1656 1651 1646 1642 1637
Temp. Rise 55 55 55 55 55
Watts
339 416 494 571 648
Medium 1720
CFM
1781 1771 1762 1752 1743
Temp. Rise 51 51 51 52 52
Watts
398 477 556 635 715
High
(a)
1830
CFM
1842 1832 1822 1812 1803
Temp. Rise 49 49 49 50 50
Watts
481 562 644 726 807
Table 17. S9V2C100D5VS Heating Airflow
S9V2C100D5VS Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 64,000
2nd Stage Capacity = 97,350
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 1094
CFM
1093 1092 1090 1089 1088
Temp. Rise 53 53 53 52 52
Watts
126 183 240 296 353
Medium Low 1296
CFM
1234 1238 1242 1247 1251
Temp. Rise 47 47 47 47 47
Watts
186 243 299 356 413
Medium
(a)
1346
CFM
1279 1268 1256 1245 1234
Temp. Rise 45 45 46 46 47
Watts
214 268 321 375 428
High
1512
CFM
1453 1429 1405 1381 1358
Temp. Rise 40 40 41 41 42
Watts
277 344 411 478 545
Heating 2nd
Stage
Low 1520
CFM
1484 1477 1469 1461 1453
Temp. Rise 60 60 61 61 61
Watts
296 370 444 518 592
Medium Low 1800
CFM
1693 1688 1684 1679 1674
Temp. Rise 53 53 53 53 53
Watts
449 533 618 702 786
Medium
(a)
1870
CFM
1768 1772 1775 1778 1781
Temp. Rise 51 50 50 50 50
Watts
505 591 678 765 852
High
2100
CFM
1969 1956 1944 1931 1918
Temp. Rise 45 45 46 46 46
Watts
723 789 854 920 986
HHeeaattiinngg aanndd CCoooolliinngg AAiirrffllooww TTaabblleess
