Trane S9V2B040U3VSBB - Page 23

S9V2-VS-SVX001-1D-EN
23
Table 14. S9V2C080U5VS Heating Airflow
S9V2C80U5VS Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 51,300
2nd Stage Capacity = 77,450
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 857
CFM
800 803 806 810 813
Temp. Rise 58 59 59 59 59
Watts
78 118 157 197 237
Medium Low 1044
CFM
939 944 950 955 961
Temp. Rise 50 50 50 50 50
Watts
114 160 207 254 301
Medium
(a)
1145
CFM
1018 1020 1021 1022 1023
Temp. Rise 46 46 46 46 47
Watts
139 190 240 291 341
High
1124
CFM
1083 1086 1089 1093 1096
Temp. Rise 43 43 43 43 43
Watts
164 217 271 324 378
Heating 2nd
Stage
Low 1190
CFM
1102 1116 1130 1144 1158
Temp. Rise 65 65 64 63 62
Watts
153 213 272 332 392
Medium Low 1450
CFM
443 905 1368 1830 2293
Temp. Rise 54 54 53 52 51
Watts
258 333 407 482 557
Medium
(a)
1590
CFM
1461 1478 1495 1513 1530
Temp. Rise 49 49 48 48 47
Watts
334 416 498 580 662
High
1700
CFM
1558 1571 1584 1597 1610
Temp. Rise 46 46 45 45 45
Watts
404 496 587 678 770
Table 15. S9V2C80U5VS Cooling Airflow
S9V2C080U5VS Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter (iwc)
Outdoor
Tonnage -
"Odt" (tons)
Airflow
Setting -
(CFM/ton)
EXTERNAL STATIC PRESSURE (IN. W. C.)
0.1 0.3 0.5 0.7 0.9
3.0
450
CFM / WATTS 1335 / 182 1347 / 241 1356 / 303 1362 / 366 1366 / 431
420
CFM / WATTS 1246 / 152 1259 / 208 1267 / 266 1273 / 326 1277 / 387
400
CFM / WATTS 1188 / 134 1200 / 188 1208 / 243 1214 / 301 1217 / 360
370
CFM / WATTS 1100 / 110 1111 / 160 1118 / 212 1123 / 266 1125 / 322
350
CFM / WATTS 1041 / 96 1052 / 143 1058 / 193 1061 / 245 1063 / 299
330
CFM / WATTS 983 / 83 993 / 128 997 / 176 999 / 225 1000 / 277
310
CFM / WATTS 925 / 72 933 / 114 936 / 159 937 / 207 936 / 257
290
CFM / WATTS 867 / 61 873 / 101 874 / 144 873 / 190 871 / 239
3.5
450
CFM / WATTS 1557 / 273 1568 / 342 1576 / 413 1581 / 486 1585 / 559
420
CFM / WATTS 1453 / 228 1465 / 292 1473 / 359 1480 / 427 1483 / 496
400
CFM / WATTS 1384 / 200 1396 / 262 1405 / 325 1411 / 391 1415 / 457
370
CFM / WATTS 1281 / 163 1293 / 221 1302 / 280 1308 / 341 1312 / 404
350
CFM / WATTS 1212 / 142 1224 / 196 1233 / 253 1239 / 311 1242 / 371
330
CFM / WATTS 1144 / 122 1155 / 173 1163 / 227 1168 / 283 1171 / 341
310
CFM / WATTS 1076 / 104 1086 / 153 1093 / 204 1097 / 257 1099 / 312
290
CFM / WATTS 1007 / 88 1017 / 134 1023 / 183 1025 / 233 1026 / 286
4.0
450
CFM / WATTS 1782 / 392 1789 / 471 1794 / 551 1797 / 632 1798 / 715
420
CFM / WATTS 1662 / 325 1671 / 399 1678 / 474 1682 / 550 1685 / 628
400
CFM / WATTS 1582 / 285 1592 / 355 1600 / 427 1606 / 500 1609 / 575
370
CFM / WATTS 1463 / 232 1474 / 297 1483 / 364 1489 / 432 1493 / 502
350
CFM / WATTS 1384 / 200 1396 / 262 1405 / 325 1411 / 391 1415 / 457
330
CFM / WATTS 1305 / 172 1317 / 230 1327 / 290 1333 / 352 1337 / 416
310
CFM / WATTS 1227 / 146 1239 / 201 1248 / 258 1254 / 317 1257 / 378
290
CFM / WATTS 1149 / 123 1160 / 175 1168 / 229 1173 / 285 1176 / 343
5.0
(a)
450
CFM / WATTS 2235 / 726 2233 / 824 2230 / 923 2224 / 1023 2216 / 1125
420
CFM / WATTS 2084 / 599 2085 / 690 2084 / 783 2082 / 877 2078 / 973
400
CFM / WATTS 1983 / 524 1986 / 611 1988 / 699 1988 / 789 1985 / 880
370
CFM / WATTS 1832 / 423 1838 / 503 1843 / 586 1845 / 669 1845 / 754
350
(a)
CFM / WATTS 1732 / 363 1740 / 440 1746 / 518 1749 / 597 1751 / 678
330
CFM / WATTS 1632 / 310 1641 / 382 1649 / 456 1654 / 531 1656 / 608
310
CFM / WATTS 1533 / 262 1543 / 330 1551 / 400 1557 / 471 1561 / 544
290
CFM / WATTS 1434 / 219 1445 / 283 1454 / 349 1460 / 416 1464 / 485
HHeeaattiinngg aanndd CCoooolliinngg AAiirrffllooww TTaabblleess
