22
S9V2-VS-SVX001-1D-EN
Table 12. S9V2B080D4VS Heating Airflow
S9V2B080D4VS Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 51,150
2nd Stage Capacity = 76,900
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 864
CFM
780 776 772 768 764
Temp. Rise 60 60 61 61 61
Watts
94 135 176 216 257
Medium Low 907
CFM
807 811 814 818 822
Temp. Rise 57 57 58 58 58
Watts
101 151 201 252 302
Medium
(a)
958
CFM
862 862 862 861 861
Temp. Rise 54 54 54 54 54
Watts
117 168 219 271 322
High
1066
CFM
977 963 949 934 920
Temp. Rise 48 49 50 51 52
Watts
128 179 230 281 332
Heating 2nd
Stage
Low 1200
CFM
1111 1104 1096 1088 1081
Temp. Rise 66 66 66 66 66
Watts
204 260 317 373 429
Medium Low 1260
CFM
1193 1201 1209 1217 1225
Temp. Rise 59 59 59 59 59
Watts
232 296 360 424 488
Medium
(a)
1330
CFM
1217 1217 1216 1215 1215
Temp. Rise 58 58 58 58 59
Watts
273 335 396 457 518
High
1480
CFM
1342 1328 1313 1299 1284
Temp. Rise 53 54 55 56 56
Watts
329 389 448 508 567
Table 13. S9V2B080U4VS and S9V2B080D4VS Cooling Airflow
S9V2B080U4VS and S9V2B080D4VS Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with
Filter (iwc)
Outdoor
Tonnage -
"Odt" (tons)
Airflow
Setting -
(CFM/ton)
EXTERNAL STATIC PRESSURE (IN. W. C.)
0.1 0.3 0.5 0.7 0.9
2.0
450
CFM / WATTS
892 / 91 899 / 136 893 / 180 872 / 222 838 / 265
420
CFM / WATTS
834 / 77 841 / 120 834 / 161 813 / 202 777 / 243
400
CFM / WATTS 785 / 67 785 / 106 781 / 146 754 / 183 737 / 229
370
CFM / WATTS
738 / 58 744 / 97 736 / 134 714 / 172 677 / 210
350
CFM / WATTS
700 / 52 705 / 89 697 / 125 675 / 161 638 / 198
330
CFM / WATTS
662 / 46 666 / 81 658 / 116 635 / 151 598 / 187
310
CFM / WATTS
624 / 40 627 / 74 619 / 107 596 / 142 558 / 177
290
CFM / WATTS 585 / 35 588 / 67 580 / 100 557 / 133 518 / 168
2.5
450
CFM / WATTS
1108 / 159 1120 / 213 1116 / 265 1098 / 315 1065 / 365
420
CFM / WATTS
1035 / 133 1046 / 184 1041 / 233 1022 / 281 989 / 328
400
CFM / WATTS
988 / 118 997 / 167 992 / 214 972 / 260 938 / 306
370
CFM / WATTS
916 / 97 924 / 143 918 / 188 897 / 231 863 / 275
350
CFM / WATTS 868 / 85 875 / 129 868 / 172 848 / 213 813 / 255
330
CFM / WATTS
820 / 74 826 / 116 819 / 157 798 / 197 762 / 237
310
CFM / WATTS
772 / 64 778 / 104 770 / 143 749 / 182 712 / 221
290
CFM / WATTS
724 / 56 729 / 94 721 / 131 699 / 168 663 / 205
3.0
450
CFM / WATTS
1326 / 257 1341 / 320 1341 / 380 1325 / 439 1296 / 497
420
CFM / WATTS 1239 / 214 1252 / 273 1250 / 330 1234 / 385 1203 / 440
400
CFM / WATTS
1181 / 188 1193 / 245 1191 / 299 1173 / 353 1142 / 405
370
CFM / WATTS
1094 / 153 1105 / 207 1101 / 258 1083 / 308 1050 / 358
350
CFM / WATTS
1036 / 133 1046 / 184 1041 / 233 1022 / 281 989 / 329
330
CFM / WATTS
978 / 115 987 / 164 982 / 210 962 / 256 928 / 302
310
CFM / WATTS 920 / 99 929 / 145 923 / 189 902 / 233 868 / 277
290
CFM / WATTS
863 / 84 870 / 128 863 / 170 843 / 212 807 / 253
4.0
(a)
450
CFM / WATTS
1769 / 570 1791 / 648 1797 / 725 1789 / 799 1766 / 873
420
CFM / WATTS
1650 / 469 1670 / 544 1675 / 616 1664 / 686 1639 / 756
400
CFM / WATTS
1571 / 410 1590 / 481 1593 / 550 1582 / 618 1555 / 685
370
CFM / WATTS 1453 / 330 1470 / 397 1472 / 462 1458 / 526 1430 / 588
350
(a)
CFM / WATTS
1375 / 284 1391 / 348 1391 / 410 1376 / 471 1347 / 530
330
CFM / WATTS
1297 / 242 1312 / 303 1311 / 363 1295 / 420 1265 / 477
310
CFM / WATTS
1219 / 205 1233 / 263 1230 / 319 1214 / 374 1183 / 428
290
CFM / WATTS
1142 / 172 1154 / 227 1151 / 280 1133 / 332 1101 / 384
HHeeaattiinngg aanndd CCoooolliinngg AAiirrffllooww TTaabblleess
