S9V2-VS-SVX001-1D-EN
21
Table 10. S9V2B060U4VS Cooling Airflow
S9V2B060U4VS Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter (iwc)
Outdoor
Tonnage -
"Odt" (tons)
Airflow
Setting -
(CFM/ton)
EXTERNAL STATIC PRESSURE (IN. W. C.)
0.1 0.3 0.5 0.7 0.9
2.0
450
CFM / WATTS 878 / 90 893 / 135 890 / 179 869 / 223 829 / 266
420
CFM / WATTS 821 / 76 834 / 119 830 / 161 808 / 202 767 / 244
400
CFM / WATTS 770 / 66 778 / 105 770 / 144 742 / 182 725 / 230
370
CFM / WATTS 725 / 57 737 / 96 731 / 134 707 / 172 664 / 211
350
CFM / WATTS 687 / 51 698 / 88 691 / 124 666 / 161 622 / 199
330
CFM / WATTS 649 / 45 659 / 80 651 / 115 625 / 151 580 / 188
310
CFM / WATTS 611 / 39 620 / 73 611 / 107 584 / 142 538 / 177
290
CFM / WATTS 573 / 34 581 / 67 571 / 99 543 / 133 496 / 168
2.5
450
CFM / WATTS 1097 / 159 1114 / 212 1114 / 265 1097 / 317 1061 / 368
420
CFM / WATTS 1023 / 133 1040 / 184 1039 / 233 1020 / 282 984 / 331
400
CFM / WATTS 976 / 117 989 / 166 990 / 214 970 / 261 932 / 308
370
CFM / WATTS 902 / 97 917 / 142 915 / 187 894 / 232 855 / 276
350
CFM / WATTS 854 / 84 868 / 128 865 / 171 843 / 214 803 / 257
330
CFM / WATTS 806 / 73 819 / 115 815 / 157 793 / 198 752 / 239
310
CFM / WATTS 759 / 63 771 / 103 766 / 143 742 / 182 700 / 222
290
CFM / WATTS 711 / 55 722 / 93 716 / 130 692 / 168 648 / 206
3.0
450
CFM / WATTS 1319 / 260 1340 / 321 1343 / 382 1328 / 441 1295 / 501
420
CFM / WATTS 1229 / 215 1249 / 274 1251 / 331 1235 / 387 1201 / 443
400
CFM / WATTS 1170 / 189 1189 / 245 1190 / 300 1173 / 354 1139 / 408
370
CFM / WATTS 1082 / 154 1100 / 206 1099 / 258 1081 / 309 1046 / 360
350
CFM / WATTS 1023 / 133 1040 / 184 1039 / 233 1020 / 282 984 / 331
330
CFM / WATTS 965 / 114 981 / 163 979 / 210 960 / 257 922 / 304
310
CFM / WATTS 907 / 98 922 / 144 919 / 189 899 / 234 860 / 278
290
CFM / WATTS 850 / 83 863 / 127 860 / 170 838 / 212 798 / 255
4.0
(a)
450
CFM / WATTS 1779 / 585 1806 / 661 1814 / 737 1805 / 812 1778 / 886
420
CFM / WATTS 1654 / 480 1679 / 552 1686 / 624 1676 / 695 1647 / 765
400
CFM / WATTS 1572 / 418 1596 / 488 1602 / 557 1590 / 625 1561 / 693
370
CFM / WATTS 1450 / 335 1472 / 401 1477 / 466 1464 / 530 1433 / 594
350
(a)
CFM / WATTS 1369 / 287 1391 / 350 1394 / 413 1380 / 474 1348 / 535
330
CFM / WATTS 1289 / 244 1310 / 305 1312 / 364 1297 / 423 1264 / 481
310
CFM / WATTS 1210 / 206 1229 / 264 1231 / 320 1214 / 376 1180 / 431
290
CFM / WATTS 1131 / 172 1149 / 227 1150 / 281 1132 / 334 1097 / 386
Table 11. S9V2B080U4VS Heating Airflow
S9V2B080U4VS Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 51,300
2nd Stage Capacity = 77,450
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 864
CFM
860 849 838 827 816
Temp. Rise 54 55 56 57 58
Watts
87 125 163 200 238
Medium Low 907
CFM
907 893 879 865 852
Temp. Rise 51 52 53 54 54
Watts
97 135 174 212 251
Medium
(a)
958
CFM
957 930 903 876 849
Temp. Rise 49 50 51 52 53
Watts
112 153 194 234 275
High
1051
CFM
1042 1015 989 962 936
Temp. Rise 45 46 47 47 48
Watts
140 182 225 267 310
Heating 2nd
Stage
Low 1200
CFM
1211 1206 1201 1197 1192
Temp. Rise 60 60 60 60 60
Watts
196 248 300 352 404
Medium Low 1260
CFM
1258 1261 1263 1265 1268
Temp. Rise 58 57 57 57 57
Watts
215 271 326 381 436
Medium
(a)
1330
CFM
1307 1303 1299 1296 1292
Temp. Rise 55 55 55 55 55
Watts
260 312 364 416 468
High
1460
CFM
1431 1412 1393 1374 1355
Temp. Rise 50 51 52 52 53
Watts
334 390 445 501 557
HHeeaattiinngg aanndd CCoooolliinngg AAiirrffllooww TTaabblleess
