Table 8. S9V2B060D3VS Cooling Airflow
S9V2B060D3VS Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter (iwc)
Outdoor
Tonnage -
"Odt" (tons)
Airflow
Setting -
(CFM/ton)
EXTERNAL STATIC PRESSURE (IN. W. C.)
0.1 0.3 0.5 0.7 0.9
1.5
450
CFM / WATTS 663 / 47 673 / 83 666 / 119 641 / 155 596 / 192
420
CFM / WATTS 621 / 41 630 / 75 621 / 109 595 / 144 549 / 180
400
CFM / WATTS 582 / 36 580 / 67 566 / 99 528 / 130 507 / 170
370
CFM / WATTS 549 / 32 556 / 63 546 / 95 517 / 128 469 / 162
350
CFM / WATTS 521 / 29 527 / 59 516 / 90 486 / 122 437 / 156
330
CFM / WATTS 492 / 26 497 / 55 486 / 85 455 / 117 405 / 150
310
CFM / WATTS 463 / 23 468 / 51 455 / 81 423 / 112 372 / 145
290
CFM / WATTS 435 / 21 438 / 48 424 / 77 391 / 107 339 / 141
2.0
450
CFM / WATTS 878 / 90 893 / 135 890 / 179 869 / 223 829 / 266
420
CFM / WATTS 821 / 76 834 / 119 830 / 161 808 / 202 767 / 244
400
CFM / WATTS 770 / 66 778 / 105 770 / 144 742 / 182 725 / 230
370
CFM / WATTS 725 / 57 737 / 96 731 / 134 707 / 172 664 / 211
350
CFM / WATTS 687 / 51 698 / 88 691 / 124 666 / 161 622 / 199
330
CFM / WATTS 649 / 45 659 / 80 651 / 115 625 / 151 580 / 188
310
CFM / WATTS 611 / 39 620 / 73 611 / 107 584 / 142 538 / 177
290
CFM / WATTS 573 / 34 581 / 67 571 / 99 543 / 133 496 / 168
2.5
450
CFM / WATTS 1097 / 159 1114 / 212 1114 / 265 1097 / 317 1061 / 368
420
CFM / WATTS 1023 / 133 1040 / 184 1039 / 233 1020 / 282 984 / 331
400
CFM / WATTS 976 / 117 989 / 166 990 / 214 970 / 261 932 / 308
370
CFM / WATTS 902 / 97 917 / 142 915 / 187 894 / 232 855 / 276
350
CFM / WATTS 854 / 84 868 / 128 865 / 171 843 / 214 803 / 257
330
CFM / WATTS 806 / 73 819 / 115 815 / 157 793 / 198 752 / 239
310
CFM / WATTS 759 / 63 771 / 103 766 / 143 742 / 182 700 / 222
290
CFM / WATTS 711 / 55 722 / 93 716 / 130 692 / 168 648 / 206
3.0
(a)
450
CFM / WATTS 1319 / 260 1340 / 321 1343 / 382 1328 / 441 1295 / 501
420
CFM / WATTS 1229 / 215 1249 / 274 1251 / 331 1235 / 387 1201 / 443
400
CFM / WATTS 1170 / 189 1189 / 245 1190 / 300 1173 / 354 1139 / 408
370
CFM / WATTS 1082 / 154 1100 / 206 1099 / 258 1081 / 309 1046 / 360
350
(a)
CFM / WATTS 1023 / 133 1040 / 184 1039 / 233 1020 / 282 984 / 331
330
CFM / WATTS 965 / 114 981 / 163 979 / 210 960 / 257 922 / 304
310
CFM / WATTS 907 / 98 922 / 144 919 / 189 899 / 234 860 / 278
290
CFM / WATTS 850 / 83 863 / 127 860 / 170 838 / 212 798 / 255
Table 9. S9V2B060U4VS Heating Airflow
S9V2B060U4VS Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 38,300
2nd Stage Capacity = 57,900
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 782
CFM
741 741 742 742 742
Temp. Rise 47 48 48 48 48
Watts
74 112 151 189 228
Medium Low 861
CFM
810 811 812 813 814
Temp. Rise 44 43 43 43 43
Watts
90 132 175 217 259
Medium
(a)
916
CFM
860 860 859 859 859
Temp. Rise 41 41 41 41 41
Watts
105 148 192 236 280
High
1027
CFM
963 957 951 945 939
Temp. Rise 37 37 37 37 37
Watts
141 183 226 268 310
Heating 2nd
Stage
Low 990
CFM
975 978 982 986 989
Temp. Rise 55 55 55 55 55
Watts
126 174 223 272 321
Medium Low 1090
CFM
1063 1070 1078 1086 1093
Temp. Rise 51 51 50 50 49
Watts
157 210 263 317 370
Medium
(a)
1160
CFM
1120 1133 1146 1159 1172
Temp. Rise 48 48 47 47 46
Watts
182 240 299 357 415
High
1300
CFM
1260 1266 1272 1279 1285
Temp. Rise 43 43 43 42 42
Watts
254 312 369 427 484
