Table 28. Evaporator data (continued)
Evap Approach Temp Front Panel Ice Building Command
Evap Differential Wtr Press Evaporator Entering Water Pressure
Evaporator Entering Water Temperature Evaporator Leaving Water Pressure
Table 29. Condenser data
Active Hot Water Setpoint Second Condenser Lvg Wtr Temp
Active Hot Water Setpoint Source Condenser Pump Override Time Remaining
Approx Cond Water Flow Condenser Pump Override
Cond Approach Temp Differential Refrigerant Pressure
Cond Differential Wtr Press Head Pressure Control Status
Cond Entering Water Temp Condenser Entering Water Pressure
Cond Leaving Water Temp Condenser Leaving Water Pressure
Cond Rfgt Pressure Condenser Refrigerant Liquid Level Ckt1
Cond Sat Rfgt Temp Economizer Bypass Valve Position Ckt1
Cond Water Flow Status
Condenser Refrigerant Liquid Level Ckt2
Outdoor Air Temp Economizer Bypass Valve Position Ckt2
Second Condenser Ent Wtr Temp
Table 30. Compressor data
Chiller Control Signal Oil Pump Control
Active Base Loading Setpoint Oil Pump Command
Active Base Loading Setpoint Source Oil Pump Discharge Pressure
Compressor Refrigerant Discharge Temperature Oil Pump Override Time Remaining
Compressor Running
Lube Differential Pressure
(CVHS)
Compressor Running Time
Lube Pump Control
(CVHS)
Compressor Starts
Lube Pump Command
(CVHS)
Hot Gas Bypass Total Time
Lube Pump Discharge Pressure
(CVHS)
IGV1 Position
Lube Pump Override Time Remaining
(CVHS)
IGV1 Position Steps
Lube Pump Suction Pressure
(CVHS)
IGV2 Position
Oil Tank Temperature
IGV2 Position Steps
Lube Flow First Stage Bearing
(CVHS)
IGV Closed Switch
Lube Flow Second Stage Bearing
(CVHS)
Oil Tank Pressure
Inboard Bearing Temp
Oil Differential Pressure
Outboard Bearing Temp
