Table 30. Compressor data (continued)
Oil Differential Pressure Switch
(CVGF, CVR only)
Outboard Bearing Pad Temperature #1
Oil Heater Command
Outboard Bearing Pad Temperature #2
Oil Heater Command 4E1
Outboard Bearing Pad Temperature #3
Oil Heater Command 4E2
Compressor Vibration
Table 31. Motor data
Active Current Limit Setpoint Motor Winding Temp #1
Active Current Limit Setpoint Source Motor Winding Temp #2
BAS Current Limit Setpoint Motor Winding Temp #3
Starter Input Power Consumption AFD Average Input Current
Starter Power Demand
AFD Input Current L1
Starter Motor Power Factor
AFD Input Current L2
Motor Speed AFD Input Current L3
Motor Frequency AFD Input Frequency
Speed Command RPM AFD Average Motor Voltage
Speed Command (CVHS) AFD Calculated Input Voltage
Average Motor Current % RLA AFD DC Bus Voltage
Electro-Mech. Phase Unbalance AFD DC Bus Current
Ext Current Limit Setpt AFD Output Power
Frequency Command
AFD Ground Current
Speed Signal AFD Inverter Base Temp
Motor Coolant Temperature AFD Rectifier Base Temp
MTC Switch
AFD Transistor Temp
Restart Inhibit Time (MP)
AFD Motor Current U % RLA
Starter Average Phase Voltage
AFD Motor Current V % RLA
Starter Motor Current L1 % RLA AFD Motor Current W % RLA
Starter Motor Current L1 AFD Motor Current U
Starter Motor Current L2 % RLA AFD Motor Current V
Starter Motor Current L2 AFD Motor Current W
Starter Motor Current L3 % RLA
AFD Motor Voltage UV
Starter Motor Current L3
AFD Motor Voltage VW
Starter Energy Consump. NonReset AFD Motor Voltage WU
Starter Energy Consump. Resettable AFD Average Input Voltage
Starter Energy Consump. Last Reset AFD Inverter Module Temp U
Starter Input Voltage AB AFD Inverter Module Temp V
Starter Input Voltage BC AFD Inverter Module Temp W
Starter Input Voltage CA
AFD Total Demand Distortion
Motor Temperature
