Table 65. Chiller Overview 1 (continued)
Graph data point
Axis
Condenser Leaving Water Temperature
Left Y-axis
Condenser Entering Water Temperature
Left Y-axis
Calculated Chiller Capacity Right Y-axis
Table 66. Chiller Overview 2
Graph data point
Axis
Average Motor Current % RLA Ckt1 1st y-axis
Left Y-axis
Average Motor Current % RLA Ckt2 1st y-axis
Left Y-axis
Motor Frequency Ckt1 1st y-axis
Left Y-axis
Motor Frequency Ckt2 1st y-axis
Left Y-axis
Oil Differential Pressure Ckt1 1st y-axis
Left Y-axis
Oil Differential Pressure Ckt2 1st y-axis
Left Y-axis
Table 67. Evaporator
Graph data point
Axis
Active Chilled Water Setpoint
Left Y-axis
Evaporator Leaving Water Temperature
Left Y-axis
Evaporator Entering Water Temperature
Left Y-axis
Evaporator Saturated Refrigerant Temperature (Ckt1 and Ckt2)
Left Y-axis
Approximate Evaporator Water Flow Right Y-axis
Table 68. Condenser
Graph data point
Axis
Active Hot Water Setpoint
Left Y-axis
Condenser Leaving Water Temperature
Left Y-axis
Condenser Entering Water Temperature
Left Y-axis
Condenser Saturated Refrigerant Temperature (Ckt1 and Ckt2)
Left Y-axis
Approximate Condenser Water Flow Right Y-axis
Table 69. Compressor
Graph data point
Axis
Average Motor Current % RLA (Ckt1 and Ckt2)
Left Y-axis
Active Current Limit Setpoint
Left Y-axis
AFD Frequency (Ckt1 and Ckt2)
Left Y-axis
IGV 1 Percent Open (Ckt1 and Ckt2)
Left Y-axis
Chiller Control Signal (Ckt1 and Ckt2)
Left Y-axis
Compressor Refrigerant Discharge Temperature (Ckt1 and Ckt2) Right Y-axis
