Input sensor tables
CNT-SVX05B-EN 107
Table 75. Hard-wired 1 k
Ω mixed-air sensor RTD values
Temperature Resistance (kΩ)
Temperature
(continued)
Resistance (kΩ)
(continued)
0°F (-17.8ºC) 930.3 77°F (25.0ºC) 1097.3
5°F (-15.0ºC) 941.2 80°F (26.7ºC) 1103.8
10°F (-12.2ºC) 952.1 85°F (29.4ºC) 1114.6
15°F (-9.4ºC) 963.0 90°F (32.2ºC) 1125.3
20°F (-6.7ºC) 973.9 95°F (35.0ºC) 1136.1
25°F (-3.9ºC) 984.8 100°F (37.8ºC) 1146.8
30°F (-1.1ºC) 995.7 105°F (40.6ºC) 1157.5
32°F (0.0ºC) 1000.0 110°F (43.3ºC) 1168.3
35°F (1.7ºC) 1006.5 115°F (46.1ºC) 1179.0
40°F (4.4ºC) 1017.4 120°F (48.9ºC) 1189.7
45°F (7.2ºC) 1028.2 125°F (51.7ºC) 1200.4
50°F (10.0ºC) 1039.0 130°F (54.4ºC) 1211.0
55°F (12.8ºC) 1049.8 135°F (57.2ºC) 1221.7
60°F (15.6ºC) 1060.7 140°F (60.0ºC) 1232.4
65°F (18.3ºC) 1071.5 145°F (62.8ºC) 1243.0
70°F (21.1ºC) 1082.2 150°F (65.6ºC) 1253.7
75°F (23.9ºC) 1093.0
Table 76. Hard-wired relative humidity sensor values
Current (mA)
Relative
humidity (%)
Relative
humidity (%)
Current (mA)
40 04
56.3 105.6
6 12.5 20 7.2
7 18.8 30 8.8
825 4010.4
931.3 5012
10 37.5 60 13.6
11 43.8 70 15.2
12 50 80 16.8
13 56.3 90 18.4
14 62.5 100 20
15 68.8
16 75
17 81.3
18 87.5
19 93.8
20 100
