Chapter 5 Configuration
78 CNT-SVX05B-EN
Table 41. Local zone sensor fan switch configuration
Parameter Valid range Default
Zone sensor fan switch Enabled or disabled Enabled
Table 42. Space temperature setpoint and limit configuration
Default setpoint Valid range Default value
Occupied heating setpoint 40 to 115°F (4.44 to 46.1°C) 71°F (21.7°C)
Occupied cooling setpoint 40 to 115°F (4.44 to 46.1°C) 74°F (23.3°C)
Occupied standby heating setpoint 40 to 115°F (4.44 to 46.1°C) 67°F (19.4°C)
Occupied standby cooling setpoint 40 to 115°F (4.44 to 46.1°C) 78°F (25.6°C)
Unoccupied heating setpoint 40 to 115°F (4.44 to 46.1°C) 60°F (15.6°C)
Unoccupied cooling setpoint 40 to 115°F (4.44 to 46.1°C) 85°F (29.4°C)
Heating setpoint low limit
1
40 to 115°F (4.44 to 46.1°C) 40°F (4.4°C)
Cooling setpoint low limit
1
40 to 115°F (4.44 to 46.1°C) 40°F (4.4°C)
Heating setpoint high limit
1
40 to 115°F (4.44 to 46.1°C) 104°F (40°C)
Cooling setpoint high limit
1
40 to 115°F (4.44 to 46.1°C) 104°F (40°C)
Thumbwheel setpoint Disable or enable Enable
1 The heating and cooling setpoint high and low limits only apply to the occupied and occupied standby setpoints and are never
applied to the unoccupied setpoints.
Table 43. Space temperature control discharge air temperature setpoint and limit configuration
Setpoints and limits Valid range Default value
Unoccupied heating discharge air temperature set-
point
38 to 150°F (3.3 to 65.6°C) 100°F (37.8°C)
Unoccupied cooling discharge air temperature set-
point
35 to 150°F (1.7 to 65.6°C) 55°F (12.8°C)
Electric heat discharge air temperature high limit
1
70 to 200°F (21.1 to 93.3°C) 115°F (46.1°C) draw-through
135°F (57.2°C) blow-through
1 Electric heat capacity is reduced if the discharge air temperature exceeds this limit.
