Inspection upon receipt
CNT-SVN01C-EN 5
Inspection upon receipt
Make sure that you have received the correct parts with your
Tracer MP581 controller. Visually inspect all parts for obvious defects or
damage. All components are thoroughly inspected before leaving the fac-
tory. Any claims for damage incurred in shipping should be filed with the
carrier.
Tracer MP581 with enclosure
The Tracer MP581 with enclosure ships with:
• Enclosure with pre-mounted termination board
• Main circuit board in a plastic frame
• Enclosure door
• Plastic bag containing four #10 (5 mm) wall anchors and four
#10 × 1.5 inch (5 × 40 mm) screws
• Installation sheet
Frame-mounted Tracer MP581
The frame-mounted Tracer MP581 ships with:
• Termination board in a plastic frame
• Main circuit board in a plastic frame
• Installation sheet
Required tools
To install the Tracer MP581 controller and check it for proper operation,
you will need the following tools:
• Drill
• Phillips-head screwdriver
• Small flat-tip screwdriver (for terminal screws)
• Digital multi-meter
Note:
The four #8 (4 mm) screws required to mount the frame-
mounted Tracer MP581 are not supplied.
