CNT-SVN01C-EN 95
Index
Numerics
0–10 Vdc inputs
check-out procedure, 30
troubleshooting, 91
wiring, 22
0–10 Vdc outputs
check-out procedure, 33
troubleshooting, 88
wiring, 25
0–20 mA inputs
check-out procedure, 31
troubleshooting, 91
wiring, 23
0–20 mA outputs
check-out procedure, 34
troubleshooting, 88
wiring, 25
24 Vac power
and Comm5 wiring, 40
and input/output wiring, 17
connector location, 20
for frame-mounted Tracer MP581, 7
grounding, 40
screw terminals, description, 19
screw-terminal location diagram, 20
total supply for inputs and outputs,
19
24 Vdc power
screw terminals, description, 19
screw-terminal location diagram, 20
total supply for inputs and outputs,
19
A
ac power, see high-voltage power
additional components, 2
adjusting brightness and contrast for
the operator display, 66
agency listing/compliance, 4
altitude specification, 1
analog inputs
check-out procedures, 27–31
troubleshooting, 89–92
wiring, 22–24
wiring guidelines, 17
wiring zone sensors, 24
See also universal inputs
analog outputs
check-out procedures, 33–34
EX2 module, 3, 67, 77
overview, 17
screw-terminal location diagram, 20
troubleshooting, 88
wiring, 25
wiring guidelines, 17
applications, 1
B
binary inputs
check-out procedure, 31
troubleshooting, 89–92
wiring, 21
wiring guidelines, 17
See also universal inputs
binary outputs
check-out procedure, 32
EX2 module, 3, 67, 77
inrush current, 26
LEDs, 82
overview, 17
powered outputs, 26
screw-terminal location diagram, 20
troubleshooting, 87
wiring, 26
wiring guidelines, 17
board, circuit,
see circuit board
books for the Tracer MP581, 93
brackets for wire ties, 18
C
calibrating the operator display, 65
CE compliance, 4
check-out procedures, 27–34, 37
0–10 Vdc inputs, 30
0–10 Vdc outputs, 33
0–20 mA inputs, 31
0–20 mA outputs, 34
analog inputs, 27–31
analog outputs, 33–34
binary inputs, 31
binary outputs, 32
linear resistance inputs, 30
pressure sensors, 37
resistance temperature detectors, 29
thermistor inputs, 27
circuit board
installing, 53–55
LED locations, 81
circuit requirements, 13
clearances
