8 BAS-SVX62E-EN
Overview
Figure 2. Dimensions (without Actuator)
Figure 3. Dimensions (Trane VAV Factory Version)
U
C
210
251.4 mm
(9.90 in.)
120.0 mm
(4.72 in.)
155.6 mm
(6.13 in.)
114.3 mm
(4.50 in.)
