14 UV-SVP01A-EN
Outside Air Actuator Description Three-point floating with spring return
Ambient Temperature Rating -25°F to 125°F
Power Consumption 5 VA
Torque 35 in-lbs.
Drive Time 90 seconds, 95 degree stroke
Face and Bypass Actuator Description Three-point floating
Ambient Temperature Rating 32°F to 122°F
Power Consumption 3 VA
Torque 35 in-lbs.
Drive Time 80-110 seconds, 95 degree stroke
2-way Control Valve Description Three-point modulating
Ambient Temperature Rating 140°F at 95% relative humidity
Drive Time 50 seconds
Max Pressure 400 psi water
Close Off Varied by size and Cv
Temperature Water 200°F maximum
Table 2: End Device Specifications
Device Characteristic Description
Standard End Devices
