Trane UniTrane Fan-Coil - Low Vertical Free Discharge Motors (115 Volt); Decimal to Fractional HP (Kw) Conversion

Electrical Data
UNT-PRC001-EN 41
Table ED-7. Low Vertical Free Discharge
Motors (115 Volt)
FC FLA HP (kW) RPM
03 0.7 .03 (0) H 1090
M 770
L 560
04 0.8 .03 (0) H 1090
M 750
L 560
06 1.1 .03 (0) H 1115
M 760
L 560
Note:
Actual rpm will vary with application and configuration.
Table ED-8. Decimal to Fractional HP (kW)
Conversion
FC Decimal Fraction
02 .03 1/30
.07 1/15
03 .04 1/25
.05 1/20
.08 1/12
04 .05 1/20
.06 1/16
.10 1/10
.13 1/8
06 .07 1/15
.12 1/8
.16 1/6
.24 1/4
08 .12 1/8
.13 1/8
.24 1/4
10 .05 .07 1/20 1/15
.06 .12 1/16 1/8
.10 .16 1/10 1/6
.13 .24 1/8 1/4
12 .05 .12 1/20 1/8
.06 .13 1/16 1/8
.10 .24 1/10 1/4
.13 .24 1/8 1/4
Low Vertical .03 1/30
03, 04, 06
Note:
Values for fractional HP’s (kW’s) are approximate values and
not necessarily the actual HP (kW).
Minimum Circuit Ampacity (MCA) and Maximum Fuse Size (MFS) Calculations for
Fan-Coils: (Motors only, No Electric Heat)
MCA = (1.25) x [Largest Motor Amperes (FLA)] + Second Motor Amperes (FLA)
(Size 10 and 12 only)
MFS or HACR* Type Circuit Breaker = 15 Amps for all Fan-Coils without
Electric Heat
(See previous Electrical Data for units with Electric Heat.)
*HACR (Heating, Air-Conditioning and Refrigeration) type circuit breakers are
required in the branch circuit wiring for all size 10 and 12 fan-coils.
