Trane UniTrane Fan-Coil Installation Operation & Maintenance

Mechanical
Specifications
UNT-PRC001-EN62
Piping Components
Ball Valve
Part Material Spec ASTM
Lever Steel, zinc plated
Seat Teflon VTFE
Packing Teflon RTFE
Stem Rod Brass B16
G-Nut Hex Brass B16
Ball Brass, B16
chrome plated
Retainer Brass B16
Body Cast Brass B584-C84400
Working Pressure
400 psi (2,758 kPa)
Manual Circuit Setter
Material
Body — Forged Brass Alloy
Trim — Forged Brass Alloy
All Wetted Parts Brass
Temperature
250 F MAX (121 C)
Working Pressure
300 psi (2,069 kPa)
Auto Circuit Setter
Material
Body — Forged Brass
Flow Cartridge — Electroless Nickel and
Stainless Steel
Temperature
250 F MAX (121 C)
Working Pressure
400 psi (2,758 kPa)
Pressure Drop
0.5 - 9.0 GPM = 2 psi ∆P (14 kPa)
10.0 - 12.0 GPM = 5 psi ∆P (34 kPa)
Ball Valve
Manual Circuit Setter
Auto Circuit Setter
Options
