Selection
Procedure
UNT-PRC001-EN 5
Digit 18 — Coil
A = 2 Row Cooling/Heating
B = 3 Row Cooling/Heating
C = 4 Row Cooling/Heating
D = 2 Row Cooling/1 Row Heating
E = 2 Row Cooling/2 Row Heating
F = 3 Row Cooling/1 Row Heating
G = 2 Row Cooling Only
H = 3 Row Cooling Only
J = 4 Row Cooling Only
K = 2 Row Cooling/Heating with
Electric Heat
L = 3 Row Cooling/Heating with
Electric Heat
M= 4 Row Cooling/Heating with
Electric Heat
P = 2 Row Cooling/Heating with
1 Row Heating
Q = 2 Row Cooling/Heating with
2 Row Heating
R = 3 Row Cooling/Heating with
1 Row Heating
Digit 19 — Coil Series
2 = 144 FPF
Digit 20 — Coil Air Vent
A = Automatic Air Vent
M= Manual Air Vent
Digits 21, 22, 23 — Electric Heat
kW — ( ) = 208V Derate
000 = No Electric Heat
010 = 1.0 kW (0.75 kW)
015 = 1.5 kW (1.1 kW)
020 = 2.0 kW (1.5 kW)
025 = 2.5 kW (1.9 kW)
030 = 3.0 kW (2.3 kW)
040 = 4.0 kW (3.0 kW)
050 = 5.0 kW (3.8 kW)
060 = 6.0 kW (4.5 kW)
070 = 7.0 kW (5.3 kW)
08 0= 8.0 kW (6.0 kW)
100 = 10.0 kW
Digit 24 — Reheat Coil
0 = None B = Hot Water Coil
A = Steam Coil
Digit 25 — Disconnect Switch
0 = None
D = Disconnect Switch
Digits 1, 2 — Unit Type
FC = Fan-Coil
Digit 3 — Cabinet Type
A = Vertical Concealed
B = Vertical Cabinet
C = Horizontal Concealed
D = Horizontal Cabinet
E = Horizontal Recessed
H = Vertical Recessed
J = Vertical Cabinet Slope Top
K = Low Vertical Concealed
L = Low Vertical Cabinet
Digit 4 — Development Sequence “B”
Digits 5, 6, 7 — Unit Size
020 040 080
030 060 100
120
Digit 8 — Unit Voltage
1 = 115/60/1 8 = 110-120/50/1
2 = 208/60/1 9 = 220-240/50/1
3 = 277/60/1
4 = 230/60/1
Digit 9 — Piping System/Placement
A = No piping, RH, No Auxiliary Drain
Pan
B = No piping, LH, No Auxiliary Drain Pan
C = No piping, RH, with Auxiliary Drain
Pan
D = No piping, LH, with Auxiliary Drain
Pan
E = No piping, RH, No Auxiliary Drain
Pan, Extended End Pocket
F = No piping, LH, No Auxiliary Drain
Pan, Extended End Pocket
G = No piping, RH, with Auxiliary Drain
Pan, Extended End Pocket
H = No piping, LH, with Auxiliary Drain
Pan, Extended End Pocket
J = With piping package, RH
K = With piping package, LH
L = With piping package, RH, Extended
End Pocket
M = With piping package, LH, Extended
End Pocket
FC B B 020 1 C M0 A 0 G 1 0 A A 2 M 000 0 0 1 0 0 0 A A 000 000 0 0 0 0 A 0 0
1 5 10 15 20 25 30 35 40 44
Digits 10, 11 — Design Sequence “M0”
Digit 12 — Inlets
A = Front Toe Space
B = Front Bar Grille
C = Front Stamped Louver
D = Bottom Stamped Louver
E = Bottom Toe Space
F = Back Duct Collar
G = Back Open Return
H = Back Stamped Louver
Digit 13 — Fresh Air Damper
0 = None
A = Manual, Bottom Opening
B = Manual, Back Opening
C = Manual, Top Opening
D = Auto, 2-Position, Bottom Opening
E = Auto, 2-Position, Back Opening
F = Auto, 2-Position, Top Opening
G = Auto, Economizer, Bottom Opening
H = Auto, Economizer, Back Opening
J = Auto, Economizer, Top Opening
K = No Damper, Bottom Opening
L = No Damper, Back Opening
M= No Damper, Top Opening
Digit 14 — Outlets
A = Front Duct Collar
B = Front Bar Grille
C = Front Stamped Louver
D = Front Quad Grille
G = Top Quad Grille
H = Top Bar Grille
J = Top Duct Collar
Digit 15 — Color
0 = No Paint (Concealed Units Only)
1 = Deluxe Beige 4 = Driftwood Grey
2 = Soft Dove 5 = Stone Grey
3 = Cameo White 6 = Rose Mauve
Digit 16 —
Tamperproof Locks/Leveling
Feet
0 = None
B = Keylock Access Door
C = Keylock Panel and Access Door
D = Leveling Feet
F=
Keylock Access Door with Leveling
Feet
G = Keylock Panel and Access Door with
Leveling Feet
Digit 17 — Motor
A = Free Discharge
B = High Static
UniTrane Fan-Coil Model Number Description
Following is a complete description of the fan-coil model number. Each digit in the model number has a corresponding code that
identifies specific unit options.
Model Number
Description
To Next Page
