Trane UniTrane Fan-Coil - Installation-Mechanical; Installation Checklist

Dimensions
and Weights
UNT-PRC001-EN 51
Low Vertical
Cabinet
Low Vertical Cabinet Unit Dimensions
Unit
Size 03 04 06
A3’-10
15
/16” 4’-8
7
/16” 5’-4
15
/16”
B2’-2
1
/4” 2’-11
3
/4” 3’-8
1
/4”
C 11
7
/16” 1’-1
5
/16” 11
7
/16”
D2’-0” 2’-6” 3’-6”
E2’-0
1
/4” 2’-9
3
/4” 3’-6
1
/4”
NOTE: 1. Coil connections are always on the drain pan side
and opposite the control box.
2. Coil connections are
5
/8” O.D. sweat.
3. All duct collar dimensions are to the outside of the
collar.
4. See page 55 for fresh air opening dimensions.
Low Vertical Cabinet, Model L
