Electrical Data
UNT-PRC001-EN 71
Table B-ED-2. Three and Four-Row Coils — Free Discharge Motors
115 Volt 208 Volt RPM
FC FLA HP (kW) FLA HP (kW) H M L
04 1.0 .06 0.6 .06 108 800 600
(.04) (.04)
06 1.4 .12 0.9 .12 108 800 600
(.09) (.09)
08 1.7 .13 1.0 .13 108 800 600
(.10) (.10)
Table B-ED-3. Three and Four-Row Coils — High Static Motors
115 Volt 208 Volt RPM
FC FLA HP (kW) FLA HP (kW) H M L
04 2.1 .13 0.9 .13 1580 1375 1240
(.10) (.10)
06 3.4 .24 1.4 .24 1475 1285 975
(.18) (.18)
08 3.4 .24 1.4 .24 1475 1285 975
(.18) (.18)
Note: Actual RPM will vary with application and configuration.
Minimum Circuit Ampacity (MCA) and Maximum Fuse Size (MFS) Calculations for fan-
coils: (Motors only)
MCA = (1.25) x [Largest Motor Amperes (FLA)]
MFS or Heating, Air-Conditioning, and Refrigeration (HACR) Type Circuit Breaker = 15
amps for all fan-coils without electric heat
Table B-ED.4. Decimal to Fractional HP (kW)
Conversion
Unit Size Decimal Fraction
04 .04 1/25
.06 1/16
.10 1/10
.13 1/8
06 .09 1/11
.12 1/8
.18 1/6
.24 1/4
08 .10 1/10
.13 1/8
.18 1/6
.24 1/4
