BAS-SVX10C-EN 41
Specifications and Agency Compliance
Agency Compliance
• United States:
– UL listed: 94, 5 VA Flammability rating; 916, Energy management equipment
– FCC Part 15, Subpart B
• Canada:
– CUL listed: 916, Energy management equipment
• Europe:
–CE marked
Specifications
Sensor operating temperature From 32°F to 122°F (0°C to 50°C)
Storage temperature From -40°F to 185°F (-40°C to 85°C)
Storage/operating humidity range 5% to 95% relative humidity (RH), noncondensing
Thermistor accuracy 0.2°C at 25°C, 1%
Setpoint functional range
Display sensor: 50°F to 89.6°F (10°C to 32°C)
All other sensors: 45°F to 95°F (7.2°C to 35°C)
Setpoint markings
Setpoint thumb wheel:
• 50°F to 85°F (in 5°F increments) and *, **
• 10°C to 29°C (in 3°C increments) and *, **
Dual setpoint slider:
• 50 to 85ºF (stamped every 5ºF)
• 10 to 29ºC (stamped every 3ºC)
Housing material
Polycarbonate/ABS blend, UV protected, UL 94-5VA flammability rating, suitable for
application in a plenum
Mounting
Fits a standard 2 in. by 4 in. junction box (vertical mount only). Mounting holes are spaced
3.2 in. (83 mm) apart on vertical center line. Includes mounting screws for junction box and
wall anchors for sheetrock walls. Overall dimensions: 2.9 in (74 mm) by 4.7 in. (119 mm)
Resolution (display sensor) 0.125ºF over a range of 60 to 80ºF (15.6 to 26.7°C); 0.25ºF when outside this range
Accuracy (display sensor) 0.5°F over a range of 55 to 85°F (12.8 to 29.4ºC)
Power consumption (display sensor) <1 VA
