Inserting a microSD Memory Card
You must insert a microSD memory card into the DrivePro before you can start recording. Please use a
MLC-based microSD memory card with 8GB, 16GB or 32GB capacity (Class 10 or above).
1. Insert a microSD memory card into its appropriate card slot on the left-hand side of the DrivePro.
Note: Always format new memory cards in the DrivePro before using them for the first time. To
format a new memory card, press the Settings button during recording and select Format Card.
WARNING! TS16GDP200 only supports FAT32 format.
2. To remove, push to eject the memory card out of the slot.
WARNING! Do not remove the memory card during shutdown to avoid damage to the
memory card and loss of recorded videos.
The following table shows approximate recording time based on capacity and resolution (for
Card Capacity 1080P 30fps 720P 30fps
8GB 1hr 20 min 2hr 20 min
16GB 2hr 40 min 4hr 40 min
32GB 5hr 20 min 9hr 30 min
