Appendix A Tag Programmer Specifications
This appendix lists the AP4119 Rail Tag Programmer physical and environmental
specifications.
The tag programmer is designed to operate in typical oce environment conditions. The tag programmer
performs to the specifications listed in Table 8 and is ready to program with a warm-up time of not more
than three minutes.
Table 8 lists the AP4119 Rail Tag Programmer parameters and specifications.
Table 8 AP4119 Rail Tag Programmer Physical and Environmental Specifications
Parameter Specification
Size (W x H x D) 14.3 x 3.2 x 11.5 in (36.3 x 8.1 x 29.2 cm)
Weight 6.10 lb (2.77 kg)
Input Voltage 24 V DC
Power Consumption 6 W
Excessive Current Protection 3-amp, 250-volt Fast-Blo fuse
Operating Temperature 32°F to 122°F (0°C to 50°C)
Storage Temperature -4°F to 185°F (-20°C to 85°C)
Humidity 95% noncondensing @77°F to 122°F (25°C to 50°C)
Enclosure Dust-proof
Operational Vibration
1.04 G
rms
, 5-500 Hz, power spectral density-uniform
0.0022 G2/Hz, 1 hour per axis
Shock 4 G
zero-to-peak
by 11 ms half-sine duration in all 3 axes
PC-to-Programmer Cable RS–232 or Type A USB (data terminal equipment)
FCC Classification Part 15, site license not required
