Transducer Techniques DPM-3 User Manual

- 15 -
MENU
KEY
DIGIT
SELECT KEY
VALUE
SELECT KEY
FiLtr
Filtering
00000
Alarm filtering
0 Alarm unfiltered
1 Alarm filtered
00000
Peak & Valley filtering
0 Peak & Valley unfiltered
1 Peak & Valley filtered
00000
Display filtering
0 Display batch average every 16 readings
1 Display filtered signal
00000
Adaptive filter threshold
0 Low adaptive filter threshold level
1 High adaptive filter threshold level
00000
Input signal filtering.
Can be applied to dis-
play, setpoint, analog
output, data output.
0 Autofilter
1 Batch average, 16 readings.
Moving averages with equivalent RC time
constants:
2 0.08 sec. 3 0.15 sec.
4 0.3 sec. 5 0.6 sec.
6 1.2 sec. 7 2.4 sec.
8 4.8 sec. 9 9.6 sec.
A Unfiltered
dEc.Pt
Decimal point
selection.
d.dddd
Determines decimal
point position & reading
resolution.
d.dddd dd.ddd ddd.dd dddd.d ddddd.
.ddddd Press ^ key to shift decimal point.
Decimal point is stored in TEDS memory.
Display shows TEds instead of StorE.
Option board dependent menu items
ALSEt. ALS34 dEU1H dEU2H dEU1b dEU2b dEU3H DEU4H DEU3b DEU4b
Menu items related to alarm setup These will only appear if a relay board is detected. If
so, please see Section14.
AnSEt. An Lo. An Hi..
Menu items related to analog output setup. These will only appear if an analog output
board is detected. If so, see Section 15.
tArE_
Tare & TEDS
selections.
00000 Calibration due
indicator.
0 Calibration due indicators enabled
1 Calibration due indicators disabled
00000 Front panel
pushbutton Tare.
0 Front panel tare enabled
1 Front panel tare disabled
00000
Auto-Tare.
0 Tare after meter reset
1 No tare after meter reset
00000 TEDS Plug and
Play indicator.
0 TEDS Plug and Play indicator enabled
1 TEDS Plug and Play Indicator disabled
00000
TEDS Plug and Play.
0 TEDS Plug and Play enabled
1 TEDS Plug and Play disabled
