8. LISTA PARTI DI RICAMBIO
8. SPARE PARTS LIST
Motori Elettrici TS - TS Electric motors
1 Corpo motore B5-B14 / Frame B5-B14
2 Statore / Wound stator
3 Albero + motore / Rotor with shaft
4 Cuscinetti / Bearings
5 Chiavetta / Key
6 Scudo posteriore / Back shield
7 Eichetta / Nameplate
8 Anello di tenuta / Spring washer
9 Viti e dadi / Rods und nuts
10 Ventola / Cooling fan
11 Seeger ventola / Fan circlip
12 Paraolio / Rubber seal ring
13 Copriventola / Fan cover
14 Viti copriventola / Self-threading screw for fan cover fixing
15 Porta terminali completo / Terminal board complete
16 Guarnizione / Terminal seal
17 Viti scatola morsettiera / Screws for terminal box fixing
18 Pressocavo / Cable gland
19 Scatola morsettiera / Terminal box (base)
20 Coperchio scatola morsettiera / Terminal box (cover)
21 Viti scudo / Mounting studs screws
22 Flangia B5 / Flange B5
23 Flangia B14 / Flange B14
24 Viti coperchio / Screws for terminal box fixing
