14 Installation (for qualified installers only)
© Travis Industries 4140808 100-01298
Gas Line Installation
Route the included flex tube through the hole in the left side of the insert and out the front as shown below.
Bend the flex tube up.
Attach the included gas shutoff valve to the end of the flex tube and gas inlet as shown below. Position so
the valve is on the right as shown.
Leak-test all gas line connections.
To Next Page
