44 Maintenance
© Travis Industries 4140808 100-01298
Wiring Diagram
CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause
improper and dangerous operation.
Replacement Parts
Caution: Use only Travis Industries replacement parts. Do not use substitute materials.
Warning: Do not operate appliance with the glass front removed, cracked, or broken. Replacement of
the glass should be done by a licensed or qualified service person.
Contact your local Travis Industries Dealer for a Replacement Parts List
Orange
Yellow
System
Jumper
Purple
Grey
Pilot Sensor
Spark
Rod
Comfort Control
Valve
Battery Box (Manual
On/Off)
Accent
Light (s)
3 Amp Fuse
Optional
Blower(s)
3 Amp Fuse
Appliance
Ground
Accessory
Power
Appliance
Ground
Green
Orange
Yellow / Green
White
Blue
IPI/CPI
JUMPER WIRE
Blue
Pink
Power
In
TOP
(4) AA Batteries
Black
Red
Yellow
Orange
Yellow
Flame
Detect
Black
Red
Purple
Grey
Black
White
Green
Integrated
Fireplace
Control
(IFC)
3.15A
FUSE
White
Black
White
Black
Black
Black
White
White
To Next Page
