Glass Frame Removal and Installation
A barrier designed to reduce the risk of burns from the hot viewing glass is provided with this
appliance and shall be installed for the protection of children and other at-risk individuals.
If the barrier becomes damaged, the barrier shall be replaced with the manufacturer’s barrier for
this appliance.
The appliance must be completely cool before removing the glass.
Do not strike or slam the glass.
1. The glass removal tool is located at the upper right of the convection area and may be removed with a ¼”
nutdriver.
NOTE: Replace the tool in this location after removing the glass frame.
2. Remove the glass frame as shown below. The glass frame is held in place with three tabs inserted
into three slots at the bottom of the insert.
