Safety Label 45
© Travis Industries 4140808 100-01298
Safety Label
The safety (listing) label is attached to the operating tag (chained to the heater near the gas control
valve). A copy is shown below.
Report No. G100405040PRT-001
Control No. 4000515
Vented Gas Fireplace Heater
616 GSR2
Tested to: ANSI Z21.88-2014/CSA 2.33-2014 “Vented Gas Fireplace Heater”, CGA 2.17-M91 (R2009) “Gas Burning
Heating Appliances for Manufactured Homes”, and CSA P.4.1-09 Testing method for measuring annual fireplace
efficiency.
This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas
Code, ANSI Z223.1/NFPA 54, or Natural Gas and Propane Installation Codes, CSA B149.1.
This appliance must be installed in accordance with the current Standard CAN/CSA Z240 MH, Mobile Housing,
in Canada or with the Manufactured Home Constructions and Safety Standard, Title 24 CFR, Part 3280, in the
United States, or when such a standard is not applicable, ANSI/NCSBCS A225.1/NFPA 501A, Manufactured Home
Installation Standard.
This vented gas fireplace heater is equipped at the factory for use with natural gas. If conversion to propane (LP)
is desired, the optional factory conversion kit must be used. Part No. 94400999 (SIT) or 225-20228 & 225-20173
(PSE) register kit may be used.
This appliance is only for use with the type(s) of gas indicated on the rating plate and may be installed in an
aftermarket, permanently located, manufactured home (USA only) or mobile home, where not prohibited by local
codes. See owner’s manual for details. This appliance is not convertible for use with other gases, unless a
certified kit is used.
This vented gas fireplace heater is not for use with air filters.
Keep burner and control compartment clean. See installation and operating instructions accompanying
appliance.
This appliance must be properly connected to a venting system in accordance with the manufacturer’s
installation instructions. Use only approved co-linear direct vent system to vent this appliance to the exterior.
See owner’s manual for approved brands of venting.
If the vent-air intake system is disconnected for servicing or any other reason, it must be resealed and / or
reinstalled.
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property
damage. Refer to the owner’s information manual provided with this appliance. For assistance or additional
information consult a qualified installer, service agency or the gas supplier.
VENTED GAS FIREPLACE HEATER - NOT FOR USE WITH SOLID FUEL
Minimum Clearances to Combustibles
Side of Insert to Adjacent Wall
Hearth Depth
Hearth to Sides of Insert
6” (153mm)
12” (305mm)
5” (127mm)
Base of Insert to Mantel
Base of Insert to Top Facing
Flue Vent
Enclosure Clearances
See Owner’s Manual
See Owner’s Manual
See Owner’s Manual
See Owner’s Manual
FAN TYPE VENTED CIRCULATOR
Blower Electrical Rating: 120 VAC, 1.8 Amps, 60 Hz, 205 Watts
Part No. 250-02468 / 250-02469 fan or blower assembly may be used
Minimum Inlet Pressure (inches W.C.)
Maximum Inlet Pressure (inches W.C.)
Manifold Pressure on “HI” (inches W.C.)
L.P.
11”
13”
11”
N.G.
5.5”
7”
3.5”
Input Rate on “HI” (BTU/Hr)
Input Rate on “LO” (BTU/Hr)
Orifice Size - Front (DMS)
Orifice Size - Rear (DMS)
L.P.
39,000
11,872
#54
1.25mm
N.G.
39,000
14,835
#44
#45
This appliance is equipped for use only at altitudes 0-2,000 feet (0-610m) in the USA. In Canada, 0-4,500 feet (0-1370m).
For altitudes above 2,000 feet, the vent configuration, orifice, or combination of both may need to be changed.
See owner’s manual for information on making these changes.
2015
2016
2014
Feb.
Mar.
Jan.
May
Jun.
Apr.
Aug.
Sep.
Jul.
Nov.
Dec.
Oct.
MANUFACTURE DATE:
WARNING: Failure to install this appliance per the manufacturer’s instructions or failure to use only parts
specifically approved with this appliance may result in property damage or personal injury.
12521 Harbour Reach Drive
Mukilteo, WA 98275
Manufactured by:
www.travisproducts.com
CAUTION:
Do not operate this appliance with glass removed, cracked or broken. Replacement of the panel(s) should be done
by a licensed or qualified service person.
0977
To Next Page
