Installation (for qualified installers only) 19
© Travis Industries 4140808 100-01298
Vent Installation
Secure the vent to the insert and termination kit using screws.
For optimum performance, keep the vent as straight as possible (no 90 bends).
Inlet
Exhaust
Duravent
Chimney Liner
Termination Kit
3" (76mm) dia.
4" (102mm) dia.
